Visual fault locator
| Main Specifications | |
|---|---|
| Product Description | Jonard Tools VFL-150 - visual fault locator |
| Device Type | Visual fault locator |
| Tests, Tools and Measurements | Visual Fault Locator (VFL), fiber breaks detection, fiber leaks detection |
| Features | For 2.5 mm ferrule, tests up to 5 km, continuous light signal mode, 2 pulsing modes |
| Fiber | 650 nm |
| Weight | 2.56 oz |
| General | |
| Device Type | Visual fault locator |
| Kit Content | Visual fault locator, FC/LC adapter |
| Media | Fiber |
| Features | For 2.5 mm ferrule, tests up to 5 km, continuous light signal mode, 2 pulsing modes |
| Tests, Tools and Measurements | Visual Fault Locator (VFL), fiber breaks detection, fiber leaks detection |
| Connectors | FC, LC, SC, ST |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 140 °F |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 185 °F |
| Battery | |
| Included Qty | 2 |
| Required Qty | 2 |
| Run Time (Up To) | 60 hour(s) |
| Supported Battery Form Factor | AAA |
| Dimensions & Weight | |
| Weight | 2.56 oz |
