Network surveillance camera - PTZ - indoor - color - 8 MP - audio - HDMI - GbE - USB 3.0 - H.264, H.265, MJPEG - DC 12 V
| Main Specifications | |
|---|---|
| Product Description | AVer MD330U - network surveillance camera |
| Device Type | Network surveillance camera - pan / tilt / zoom - indoor |
| Audio | Yes: built-in microphone, built-in speaker |
| Dimensions (WxDxH) | 6.6 in x 4.9 in x 8 in |
| Weight | 3.64 lbs |
| Connectivity Technology | Wired |
| Camera | Color |
| Optical Zoom | 30 x |
| Video Modes | 1080i, 1080p, 720p, 4K |
| Optical Sensor Type | Exmor CMOS - 1/2.8" - 8 MP |
| Minimum Illumination | 0.7 lux F1.6 - 50 IRE |
| Focal Length | 4.3 mm - 129 mm |
| Focus Adjustment | Automatic |
| Lens Iris | F/1.6-4.7 |
| Panning Range (degree) | -170 to +170 |
| Tilting Range (degree) | -35 to +90 |
| Interfaces | USB 3.0, HDMI, Ethernet 10Base-T/100Base-TX/1000Base-T |
| Control Interface | RS-232 |
| Cables Included | 1 - USB cable - external |
| Voltage | AC 100-240 V, DC 12 V |
| Features | Auto gain control, manual gain control, auto exposure control, Backlight Compensation (BLC), manual exposure, Wide Dynamic Range (WDR), auto white balance, manual white balance, 2D Noise Reduction Technology, 3D Noise Reduction Technology, Audio Noise Reduction, detachable camera module |
| Manufacturer Warranty | 3-year warranty |
| Environmental Parameters (operating) | 32 °F - 95 °F; 20 - 80% relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Audio Support | Yes: built-in microphone, built-in speaker |
| Audio Formats | PCM |
| Connectivity Technology | Wired |
| Width | 6.6 in |
| Depth | 4.9 in |
| Height | 8 in |
| Weight | 3.64 lbs |
| Expansion / Connectivity | |
| Ports | Serial RS-232 ¦ HDMI ¦ USB 3.0 ¦ LAN |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - AVerCare - 3 years |
| Miscellaneous | |
| Included Accessories | Remote control, screws |
| Cables Included | 1 x USB cable - external |
| Power | |
| Power Requirements | DC 12 V |
| Power Device | Power adapter - external AC 100-240 V 36 watt |
| Software / System Requirements | |
| Software Included | AVer PTZ Manager |
| OS Required | Microsoft Windows 7 or later |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Relative Humidity (operating) | 20 - 80% |
| Camera | |
| Type | Color - pan / tilt / zoom - indoor |
| Digital Video Format | H.264, H.265, MJPEG |
| Video Modes | 1080i, 1080p, 720p, 4K |
| Digital Zoom | 3 |
| Exposure Range | 1/1 sec - 1/10000 sec |
| Minimum Illumination | 0.7 lux F1.6 - 50 IRE |
| Features | Auto gain control, manual gain control, auto exposure control, Backlight Compensation (BLC), manual exposure, Wide Dynamic Range (WDR), auto white balance, manual white balance, 2D Noise Reduction Technology, 3D Noise Reduction Technology, Audio Noise Reduction, detachable camera module |
| Lens Construction | |
| Optical Zoom | 30 x |
| Focal Length | 4.3 mm - 129 mm |
| Lens Iris | F/1.6-4.7 |
| Focus Adjustment | Automatic |
| Horizontal Field of View (degree) | 2.34 - 65.1 |
| Vertical Field of View (degree) | 1.36 - 38.4 |
| Diagonal Field of View (degree) | 2.64 - 72.9 |
| Image Sensor | |
| Type | 8 MP Exmor CMOS 1/2.8" |
| Interfaces | |
| Video | HDMI |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, TCP/IP, ARP, DHCP, HTTP, IGMP, RTCP, RTMP, RTP, RTSP, UDP/IP |
| Computer Interface | USB 3.0 |
| Control Interface | RS-232 |
| Panning | |
| Range (degree) | -170 to +170 |
| Speed (degree/sec) | Up to 200 |
| Tilting | |
| Range (degree) | -35 to +90 |
| Speed (degree/sec) | Up to 200 |
