NVR - 8 channels - 1 x 4 TB - networked - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Speco NRE Series N8WNRE - standalone NVR - 8 channels |
| Device Type | NVR - 8 channels - networked - rack-mountable |
| IP Cameras Supported | 8 |
| Frame Rate | 30 fps |
| Compression Format | H.264, H.265 |
| Hard Drive | 1 x 4 TB |
| Hard Drive(s) Supported | Quantity: 1 - total capacity: 16 TB |
| Dimensions (WxDxH) | 15.2 in x 11.7 in x 3.5 in |
| Manufacturer Warranty | 5 year limited warranty |
| General | |
| Device Type | NVR - rack-mountable |
| Video Channels | 8 |
| IP Cameras Supported | 8 |
| Audio Channels | 8 |
| Compression Format | H.264, H.265 |
| Package Content | Remote control, mouse |
| Compliant Standards | NDAA Section 889 |
| Warranty | 5 year limited warranty |
| Networking | |
| DDNS Support | Yes |
| Supported Protocols | P2P, TCP/IP, PPPoE, DHCP, DNS, UPnP, NTP, SMTP |
| Features | EZ Search 2.0, EZ Wizards, Disk S.M.A.R.T. Scan, 96W PoE power budget |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 90% |
| Hard Drive | |
| Quantity Installed | 1 |
| Quantity Supported | 1 |
| Capacity | 4 TB |
| Interface | Serial ATA |
| Supported Max Total Capacity | 16 TB |
| Connections | |
| Video Input Ports | RJ-45 x 8 (POE) |
| Video Output Ports | HDMI x 1, VGA x 1 |
| Audio Input Ports | RCA x 1 |
| Audio Output Ports | RCA x 1 |
| Alarm Ports | Alarm input x 8, alarm output x 4 |
| Other Ports | USB 2.0 x1, USB 3.0 x 1 |
| Dimensions & Weight | |
| Width | 15.2 in |
| Depth | 11.7 in |
| Height | 3.5 in |
| Security DVR | |
| Frame Rate (Record) | 30 fps |
| Video Recording Resolution | 8 Megapixels, 5 Megapixels, 4 Megapixels, 3 Megapixels, 1920x1080, 1280x720, 960x480, CIF, D1 |
| Playback Search | Face detection, smart search, motion detection, date/time, event, museum, bookmark, log, snapshot |
| Record Events | Face detection, analytics, continuous, motion detection, sensor, scheduled, manual |
| Networked | Yes |
| Features | Wall-mountable, Line Crossing Detection, human detection, vehicle detection, 2-way audio communication, 960H Technology, Fisheye Dewarp function, smartphone support, intrusion detection, people counting, crowd detection, tripwire detection, Video Tampering Alerts, face detection |
