Receipt printer - thermal line - - 203 x 203 dpi - up to 401.6 inch/min - serial, USB, LAN - cutter - Epson black
| Main Specifications | |
|---|---|
| Product Description | Epson OmniLink TM-L100 - receipt printer - B/W - thermal line |
| Printer Type | Receipt printer - thermal line - B/W |
| Weight | 4.19 lbs |
| Max Media Size | Roll (3.15 in) |
| Max Media Size (Custom) | 3.15 in |
| Print Speed | Up to 401.6 inch/min - max speed |
| Max Resolution (B&W) | 203 x 203 dpi |
| Cutter | Yes |
| Interface | Serial, USB, LAN |
| RAM Installed (Max) | 4 KB |
| Barcodes | UPC-A, UPC-E, EAN/JAN-13, EAN/JAN-8, Code 93, Code 128, GS1-128, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, Code 39, ITF, Codabar, PDF417, QR code |
| Media Type | Linerless labels, thermal paper, receipt paper |
| Max Characters Qty | 95 |
| Features | Liner-free label compatible, Label Taken Sensor (LTS), paper near end sensor |
| System Requirements | Android, Apple iOS, Linux, Microsoft Windows |
| Enclosure Color | Epson black |
| Manufacturer Warranty | 1-year warranty |
| Dimensions (WxDxH) | 5.5 in x 5.8 in x 8.1 in |
| General | |
| Printer Type | Receipt printer - thermal line - monochrome |
| Enclosure Color | Epson black |
| Expansion / Connectivity | |
| Connections | 1 x USB - 4 pin USB Type B ¦ 1 x serial ¦ 1 x LAN |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Included Accessories | Rubber feet, 40 mm width paper guide, 58 mm width paper guide |
| MTBF | 360,000 hour(s) |
| Features | Back feed |
| Compliant Standards | FCC Class A certified, ICES-003 Class A, RoHS |
| Printer | |
| Print Speed | Up to 401.6 inch/min - max speed |
| Built-in Devices | Buzzer |
| Connectivity Technology | Wired |
| Interface | Serial, USB, LAN |
| Max Resolution (B&W) | 203 x 203 dpi |
| Max Characters Qty | 95 |
| Features | Liner-free label compatible, Label Taken Sensor (LTS), paper near end sensor |
| Auto Cutter | Yes |
| Barcodes | UPC-A, UPC-E, EAN/JAN-13, EAN/JAN-8, Code 93, Code 128, GS1-128, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, Code 39, ITF, Codabar, PDF417, QR code |
| RAM | |
| RAM Installed (Max) | 4 KB |
| Media Handling | |
| Media Type | Linerless labels, thermal paper, receipt paper |
| Max Media Size | Roll (3.15 in) |
| Max Media Size (Custom) | 3.15 in |
| Media Sizes | Roll (3.15 in), Roll (2.3 in), Roll (1.6 in) |
| Roll Maximum Outer Diameter | 4 in |
| Roll Core Diameter | 0.71 in, 1.25 in |
| Media Feeders | 1 x manual - 1 roll - Roll (3.15 in) |
| Power | |
| Power Device | Power adapter - external |
| Software / System Requirements | |
| Software Included | ePOS, TM Utility |
| OS Required | Android, Apple iOS, Linux, Microsoft Windows |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 90% |
| Dimensions & Weight | |
| Width | 5.5 in |
| Depth | 5.8 in |
| Height | 8.1 in |
| Weight | 4.19 lbs |
