Storage controller (RAID) - M.2 - M.2 NVMe Card - RAID RAID 0, 1, 4, 5, 10 - PCIe 4.0 x16 - for Apple Mac Pro (Late 2019)
| Main Specifications | |
|---|---|
| Product Description | OWC Accelsior 8M2 - storage controller (RAID) - M.2 NVMe Card - PCIe 4.0 x16 |
| Device Type | Storage controller (RAID) - plug-in card |
| Bus Type | PCIe 4.0 x16 |
| Expansion Bays | 8 x internal - M.2 2280 |
| Hard Drive Form Factor Compatibility | M.2 |
| Interface | M.2 NVMe Card |
| Supported Devices | Disk array (RAID), solid state drive |
| Max Storage Devices Qty | 8 |
| RAID Level | RAID 0, RAID 1, RAID 4, RAID 5, RAID 10 |
| Product Material | Aircraft-grade aluminum |
| System Requirements | Windows 10 (32/64 bits), Microsoft Windows Server 2016, Apple macOS High Sierra 10.13, Apple macOS Mojave 10.14, Apple macOS Catalina 10.15, Apple macOS Monterey 12.x, Apple macOS Big Sur 11.x |
| Dimensions (WxDxH) | 0.9 in x 12.8 in x 5 in |
| Weight | 26.45 oz |
| Manufacturer Warranty | 3-year warranty |
| Designed For | Apple Mac Pro (Late 2019) |
| General | |
| Device Type | Storage controller (RAID) - plug-in card |
| Hard Drive Form Factor Compatibility | M.2 |
| Host Bus | PCIe 4.0 x16 |
| Product Material | Aircraft-grade aluminum |
| Expansion / Connectivity | |
| Bays | 8 x internal - M.2 2280 |
| Interfaces | 8 x M.2 Card - M.2 M key (internal) |
| Connections | 1 x PCIe 4.0 x16 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Torx T8S driver, Phillips PH1 screwdriver |
| Features | LED indicator, built-in cooling fan, full-height, full-length |
| Compliant Standards | Plug and Play |
| Software / System Requirements | |
| Software Included | SoftRAID XT, Acronis Cyber Protect Home Office (1 year subscription) |
| OS Required | Windows 10 (32/64 bits), Microsoft Windows Server 2016, Apple macOS High Sierra 10.13, Apple macOS Mojave 10.14, Apple macOS Catalina 10.15, Apple macOS Monterey 12.x, Apple macOS Big Sur 11.x |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 90% (non-condensing) |
| Storage Controller | |
| Interface | M.2 NVMe Card |
| Supported Devices | Disk array (RAID), solid state drive |
| Max Storage Devices Qty | 8 |
| RAID Level | RAID 0, RAID 1, RAID 4, RAID 5, RAID 10 |
| Dimensions & Weight | |
| Width | 0.9 in |
| Depth | 12.8 in |
| Height | 5 in |
| Weight | 26.45 oz |
| Compatibility Information | |
| Designed For | Apple Mac Pro (Late 2019) |
