Expansion module - SIM x 8 + Gigabit Ethernet x 4
| Main Specifications | |
|---|---|
| Product Description | Pepxim SIM Injector - expansion module - SIM x 8 + Gigabit Ethernet x 4 |
| Device Type | Expansion module |
| Form Factor | External |
| Ports | SIM x 8 + Gigabit Ethernet x 4 |
| Dimensions (WxDxH) | 5.8 in x 5 in x 1.6 in |
| Weight | 15.17 oz |
| Cabling Type | Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Power | DC 12 - 56 V |
| General | |
| Device Type | Expansion module |
| Form Factor | External |
| Expansion / Connectivity | |
| Expansion Slots | 8 (total) / 8 (free) x SIM |
| Interfaces | 4 x 1000Base-T - RJ-45 |
| Networking | |
| Ports | SIM x 8 + Gigabit Ethernet x 4 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Voltage Required | DC 12 - 56 V |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 149 °F |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 5.8 in |
| Depth | 5 in |
| Height | 1.6 in |
| Weight | 15.17 oz |
