LCD projector - 4000 lumens - XGA (1024 x 768) - 4:3 - LAN
| Main Specifications | |
|---|---|
| Product Description | InFocus LightPro Advanced LCD Series IN1024 - LCD projector - LAN |
| Device Type | LCD projector |
| Brightness | 4000 lumens |
| Contrast Ratio | 50000:1 |
| Resolution | XGA (1024 x 768) |
| Native Aspect Ratio | 4:3 |
| Lamp Type | UHP |
| Lamp Life Cycle | Up to 20000 hour(s) |
| Video Input | LAN - AVI |
| Speakers | Speaker(s) - integrated |
| Power | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 150 watt |
| Dimensions (WxDxH) | 13.6 in x 10.3 in x 3.9 in |
| Weight | 7.28 lbs |
| General | |
| Device Type | LCD projector |
| Networking | Ethernet |
| Expansion / Connectivity | |
| Interfaces | 2 x HDMI - 19 pin HDMI Type A ¦ 1 x VGA input - 15 pin HD D-Sub (HD-15) ¦ 1 x composite video input - RCA ¦ 1 x serial RS-232 - 9 pin D-Sub (DB-9) (management) ¦ 1 x USB 2.0 - 4 pin USB Type B (management) ¦ 1 x VGA output - 15 pin HD D-Sub (HD-15) ¦ 1 x USB 2.0 - 4 pin USB Type B ¦ 1 x audio line-in - mini-phone stereo 3.5 mm ¦ 1 x audio line-in - RCA x 2 ¦ 1 x audio line-out - mini-phone stereo 3.5 mm ¦ 1 x network - RJ-45 ¦ 1 x USB - 4 pin USB Type A |
| Miscellaneous | |
| Included Accessories | Wireless remote control |
| Cables Included | 1 x VGA cable |
| Security Features | Security lock slot (cable lock sold separately), security bar, keypad lock |
| Security Slot Type | Kensington security slot |
| Compliant Standards | CB, EAC, cTUVus, CCC, FCC, UKCA, NOM, PSB, BIS, WEEE, EU RoHS, China RoHS, CEL, CECP, HDCP 1.4 |
| Power | |
| Power Source | AC |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 150 watt |
| Power Consumption Stand by | 0.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% |
| Sound Emission | 32 dB |
| Sound Emission (Economic Mode) | 26 dB |
| Video Input | |
| Video Interfaces | HDMI, VGA, composite video, USB |
| Digital Video Format | AVI |
| LAN and Wireless Image Transferring Protocols | Wired LAN |
| Dimensions & Weight | |
| Width | 13.6 in |
| Depth | 10.3 in |
| Height | 3.9 in |
| Weight | 7.28 lbs |
| Projector | |
| Brightness | 4000 lumens |
| Contrast Ratio | 50000:1 |
| Projection Distance | 3 ft - 36 ft |
| Throw Ratio | 1.48 - 1.78:1 |
| Uniformity | 85 % |
| Digital Zoom Factor | 4x |
| Resolution | XGA - XGA (1024 x 768) (native) / 3840 x 2160 (resized) |
| Native Aspect Ratio | 4:3 |
| Max Sync Rate (V x H) | 85 Hz x 100 kHz |
| Lamp Type | UHP |
| Lamp Life Cycle | Up to 20000 hour(s) |
| Features | 3LCD Technology, Auto Vertical Keystone, Auto Horizontal Keystone, AMX Device Discovery, Crestron RoomView, PJlink, PDF files support, BMP photo playback, GIF photo playback, JPEG photo playback, PNG photo playback, TIFF photo playback |
| Lens | |
| Focus Type | Manual |
| Lens Aperture | F/1.6-1.76 |
| Zoom Type | Manual |
| Zoom Factor | 1.2x |
| Keystone Correction Direction | Vertical, horizontal |
| Vertical Keystone Correction | -30 / +30 |
| Horizontal Keystone Correction | -30 / +30 |
| Speakers | |
| Type | Integrated |
| Output Power / Channel | 16 watt |
