Docking station - USB-C 3.1 / Thunderbolt 3 - 2 x DP - 1GbE
| Main Specifications | |
|---|---|
| Product Description | Cable Matters - docking station - USB-C 3.1 / Thunderbolt 3 - 2 x DP - 1GbE |
| Product Type | Docking station |
| Docking Interface | USB-C 3.1 / Thunderbolt 3 |
| Video Interfaces | 2 x DP |
| Dimensions (WxDxH) | 7.9 in x 2.8 in x 1 in |
| Networking | Gigabit Ethernet |
| General | |
| Product Type | Docking station |
| Width | 7.9 in |
| Depth | 2.8 in |
| Height | 1 in |
| Expansion / Connectivity | |
| Interfaces | 2 x USB 2.0 - 4 pin USB Type A ¦ 2 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 2 x display / video - DisplayPort - 20 pin DisplayPort ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x USB 3.1 Gen 2 - 9 pin USB Type A ¦ 1 x USB 3.1 Gen 2 with Power Delivery - 24 pin USB-C ¦ 1 x microphone - mini-phone mono 3.5 mm ¦ 1 x headphones - mini-phone stereo 3.5 mm |
| Miscellaneous | |
| Input Device | SD card reader, microSD card reader |
| Cables Included | 1 x USB-C cable - external |
| Included Accessories | Stand |
| Features | On/off switch, 4K Ultra HD, 80W power delivery |
| Compliant Standards | USB Power Delivery 3.0 |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Video | |
| Max Resolution Details | 3840 x 2160 - 60 Hz (DisplayPort only) ¦ 2560 x 1440 - 60 Hz (Dual Display) |
| System Requirements | |
| OS Required | Microsoft Windows |
