86" Diagonal Class LED-backlit LCD display - interactive - 4K UHD (2160p) 3840 x 2160
| Main Specifications | |
|---|---|
| Product Description | ViewSonic ViewBoard IFP8662 86" LED-backlit LCD display - 4K - for interactive communication |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 86" |
| Commercial Use | Yes - interactive |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| Connectivity | Wi-Fi (optional), LAN |
| PC Interface | USB, serial RS-232, USB 3.0, USB-C 3.1 |
| LCD Backlight Technology | LED backlight |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Speaker System | 2 speakers, subwoofer |
| Storage Capacity | 32 GB |
| USB | Yes |
| Included Accessories | Remote control, 2 styluses, 8 screws, camera plate, 5 clamps, RS232 adapter |
| Power Consumption Operational | 160 watt |
| Power Consumption Stand by | 0.5 watt |
| Dimensions (WxDxH) | 77.2 in x 3.1 in x 46.1 in |
| Weight | 140.43 lbs |
| Environmental Standards | ENERGY STAR Qualified, EPEAT Silver |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption (Max) | 580 watt |
| Power Consumption Operational | 160 watt |
| Diagonal Class | 86" |
| Commercial Use | Yes - interactive |
| Operating System | Android OS 8.0 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| PC Interface | USB, serial RS-232, USB 3.0, USB-C 3.1 |
| Protection | Tempered glass protection |
| Width | 77.2 in |
| Depth | 3.1 in |
| Height | 46.1 in |
| Weight | 140.43 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site ¦ Limited warranty - backlight - 3 years - on-site |
| Miscellaneous | |
| Included Accessories | 2 styluses, 8 screws, camera plate, 5 clamps, RS232 adapter |
| Cables Included | USB-C cable ¦ USB cable ¦ HDMI cable |
| Compliant Standards | CB, FCC, cTUVus, REACH, ERP, Mexico Energy label, UKCA |
| Power | |
| Power Device | Power supply |
| Power Consumption Stand by | 0.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Display | |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| LCD Backlight Technology | LED backlight |
| Coating | Anti-glare, 9H Hard |
| Image Contrast Ratio | 1200:1 |
| Brightness | 350 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Touchpoints Qty | 20 |
| Response Time | 8 ms |
| Backlight Life | 30,000 hours |
| Additional Features | Projected Capacitive Technology (PCAP) |
| Connections | |
| Connector Type | 4 x HDMI input ¦ HDMI output ¦ USB-C 3.1 ¦ 5 x USB 3.0 ¦ USB 2.0 ¦ Audio line-out / SPDIF output ¦ Audio output ¦ Gigabit LAN ¦ LAN ¦ RS-232 ¦ USB 2.0 |
| Remote Control | |
| Type | Remote control |
| Battery Included | Yes |
| Audio System | |
| Speaker System | 2 speakers, subwoofer |
| Output Power / Total | 29 watt |
| Speakers | 2 x main channel speaker - 12 watt ¦ 1 x subwoofer - 15 watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 83.2 in |
| Depth (Shipping) | 10.6 in |
| Height (Shipping) | 50.8 in |
| Weight (Shipping) | 185.85 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi (optional), LAN |
| LAN Protocol | Fast Ethernet |
| Stands & Mounts | |
| Flat Panel Mount Interface | 800 x 600 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| Configuration | ARM Cortex-A73 Quad-Core ( 1.2 GHz ) - 3 GB - 32 GB |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Silver |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
