Server - rack-mountable 1U - no CPU - RAM 0 GB - no HDD - AST2500 / Radeon Graphics (CPU required) - Gigabit Ethernet, 10 Gigabit Ethernet - no OS - monitor: none
| Main Specifications | |
|---|---|
| Product Description | ASRock Rack 1U2LW-X570/2L2T - rack-mountable no CPU - 0 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 1U |
| Processor | No CPU |
| Processor Socket | Socket AM4 |
| RAM | 0 GB DDR4 SDRAM |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | ASPEED AST2500 / AMD Radeon Graphics (CPU required) |
| Video Memory | 16 MB DDR4 SDRAM |
| Networking | 1GbE, 10GbE |
| Power | (50 - 60 Hz) |
| OS Provided | No operating system |
| Dimensions (WxDxH) | 19 in x 15.5 in x 1.7 in |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Built-in Devices | System temperature monitor |
| Internal Bays Qty | 2 |
| Front Accessible Bays Qty | 1 |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x M.2 Card - 2242/2260/2280/22110 (Key M, PCIe and SATA mode) ¦ 1 (total) / 1 (free) x M.2 Card - 2242/2260/2280 (Key M, PCIe and SATA mode) |
| Interfaces | 2 x LAN (10Gigabit Ethernet) - RJ-45 ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x management - RJ-45 ¦ 2 x USB 3.2 Gen 1 ¦ 2 x USB 3.2 Gen 2 ¦ 1 x VGA ¦ 1 x HDMI ¦ 1 x serial |
| Miscellaneous | |
| Compliant Standards | Plug and Play, ACPI 2.0 |
| RAM | |
| Installed Size | 0 GB |
| Technology | DDR4 SDRAM |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 4 (empty) |
| Networking | |
| Ethernet Controller | Realtek RTL8211E |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Power Provided | 315 Watt |
| 80 PLUS Certification | 80 PLUS Gold |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | ASPEED AST2500 / AMD Radeon Graphics (CPU required) |
| Video Memory | 16 MB DDR4 SDRAM |
| Video Interfaces | VGA, HDMI |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 19 in |
| Depth | 15.5 in |
| Height | 1.7 in |
| Processor / Chipset | |
| CPU | No CPU |
| CPU Upgradability | Upgradable |
| CPU Socket | Socket AM4 |
| Chipset Type | AMD X570 |
| Motherboard Name | ASRock Rack X570D4U-2L2T |
