Complete Solution Kit - video/audio/infrared extender - 4 ports - up to 197 ft
| Main Specifications | |
|---|---|
| Product Description | Monoprice Blackbird - Complete Solution Kit - video/audio/infrared extender |
| Device Type | Video/audio/infrared extender |
| Ports Qty | 4 |
| Form Factor | External |
| Data Transfer Rate | 18 Gbps |
| Max Transfer Distance | 197 ft |
| Power Over Ethernet (PoE) | PoC |
| Power | AC 100-240 V |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Video/audio/infrared extender |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI - 19 pin HDMI Type A ¦ 1 x HDMI (loop output) - 19 pin HDMI Type A ¦ 1 x IR (input) - mini jack ¦ 1 x micro-USB (service) - micro-USB Type B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | EDID compatible |
| Networking | |
| Ports Qty | 4 |
| Connectivity Technology | Wired |
| Data Transfer Rate | 18 Gbps |
| Max Resolution | 4096 x 2160 @ 60 Hz |
| Max Video Bandwidth | 18 GHz |
| Max Transfer Distance | 197 ft |
| Status Indicators | Port status, power, loop, input |
| Features | 7.1 channel audio support, power over cable (PoC), 12-bit Deep Color support, Advanced EDID Management, LPCM 7.1 support, Dolby TrueHD support, Dolby Digital Plus support, DTS-HD Master Audio support, splitter mode, DTS support, DTS-HD support, LPCM 5.1 support, DTS:X support, DTS Digital Surround 5.1 support, Dolby Digital support, HDR 4K60 4:4:4 compatible, 10-bit Deep Color support, 8-bit Deep Color support, HDR10 support, Dolby Vision HDR support, HDR10+ support, HDMI loop out, Hybrid Log-Gamma (HLG) support, 4K UHD video streaming, 4:4:4 chroma subsampling support, audio extractor, LPCM 2.0 support |
| Compliant Standards | HDCP 2.2 |
| Power | |
| Power Over Ethernet (PoE) | PoC |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 14 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 90% (non-condensing) |
| Dimensions & Weight | |
| Dimensions (WxDxH) / Weight Details | Transmitter: 8.3 in x 3.9 in x 1 in / 21.8 oz ¦ Receiver: 3.5 in x 2.4 in x 0.7 in / 5.5 oz |
