Presentation controller
| Main Specifications | |
|---|---|
| Product Description | Crestron AirMedia Series 3 AM-3200-WF presentation controller |
| Type | Presentation controller |
| Dimensions (WxDxH) | 7.4 in - 7 in - 1.3 in |
| Weight | 30.33 oz |
| Manufacturer Warranty | 3 years |
| General | |
| Type | Presentation controller |
| Width | 7.4 in |
| Depth | 7 in |
| Height | 1.3 in |
| Weight | 30.33 oz |
| Manufacturer Warranty | |
| Warranty | 3 years |
| Power | |
| Power Consumption | 14 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Terminals | |
| Terminals | (1) x HDMI input - 19 pin HDMI Type A ¦ (1) x HDMI output - 19 pin HDMI Type A ¦ (1) x USB 2.0 - 4 pin USB type A ¦ (1) x USB 3.0 - 9 pin USB Type A ¦ (1) x USB 3.0 - 9 pin USB Type B ¦ (2) x network - RJ-45 ¦ (1) x infrared output - 2-pin terminal block ¦ (1) x serial - 5-pin terminal block ¦ (1) x balanced audio output - 5-pin terminal block - stereo |
| Studio & Production Equipment | |
| Features | EDID support, Power Over Ethernet support, HDCP 2.2 compliant, HDCP 1.4 compliant, 4K60 signal support, IEEE 802.11 a/b/g/n/ac/ax support |
