Video/audio extender - 10Mb LAN, HDMI, DisplayPort - up to 230 ft - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series DisplayPort to HDMI over Cat6 Extender Kit, Wall Plate, 4K 60 Hz, 4:4:4, PoC, HDCP 2.2, 230 ft. (70.1 m), TAA - video/audio extender - HDMI, DisplayPort, 10Mb LAN - TAA Compliant |
| Device Type | Video/audio extender |
| Form Factor | In-wall / wall / rack mountable |
| Localization | Australia, Europe, North America, United Kingdom |
| Data Link Protocol | HDMI, DisplayPort, 10Mb LAN |
| Max Transfer Distance | 230 ft |
| Power Over Ethernet (PoE) | PoC |
| Power | AC 100-240 V |
| TAA Compliant | Yes |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Video/audio extender |
| Form Factor | In-wall / wall / rack mountable |
| Color | White |
| Localization | Australia, Europe, North America, United Kingdom |
| Expansion / Connectivity | |
| Interfaces | 1 x DisplayPort (input) female ¦ 1 x HDMI (local unit) - Type A female ¦ 1 x HDMI (output) - Type A female ¦ 1 x network (receiver) - RJ-45 female ¦ 1 x network (transmitter) - RJ-45 female |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Included Accessories | 4 power plug adapters, 4 x screws |
| Mounting Kit | Included |
| Compliant Standards | REACH, RoHS, FCC, CCC, GS, TUV, UL, cUL, DisplayPort 1.2a |
| TAA Compliant | Yes |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI, DisplayPort, 10Mb LAN |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Max Transfer Distance | 230 ft |
| Status Indicators | Data |
| Features | HDR support, 4K resolution support, 7.1 channel audio support, video mirror mode, 36-bit True Color support, 3D support, LPCM 5.1 support, LPCM 7.1 support, LPCM 2.0 support, 4:4:4 chroma subsampling support, dual display support |
| Compliant Standards | HDCP 2.2, HDCP 1.4 |
| Power | |
| Power Over Ethernet (PoE) | PoC |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 85% (non-condensing) |
| Dimensions & Weight | |
| Dimensions (WxDxH) / Weight Details | Transmitter: 2.8 in x 1.3 in x 4.5 in / 22.9 oz ¦ Receiver: 2.8 in x 1.3 in x 4.5 in / 22.9 oz |
