4K 60 Hz, HDR, 4:4:4, PoC, HDCP 2.2, 230 ft. (70.1 m), TAA - Video/audio extender - receiver - over CAT 6 - up to 230 ft - TAA Compliant - for P/N: B127A-002-BH, B127A-002-BHPH2, B127A-004-BH, B127A-004-BHPH3, B127A-008-BH
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series HDMI over Cat6 Receiver 1-Port, Pigtail - 4K 60 Hz, HDR, 4:4:4, PoC, HDCP 2.2, 230 ft. (70.1 m), TAA - video/audio extender - TAA Compliant |
| Device Type | Video/audio extender (receiver) |
| Form Factor | External |
| Transmission Medium | CAT 6 |
| Max Transfer Distance | 230 ft |
| Power Over Ethernet (PoE) | PoC |
| Dimensions (WxDxH) | 1.9 in x 2.9 in x 0.7 in |
| TAA Compliant | Yes |
| Manufacturer Warranty | 1-year warranty |
| Designed For | P/N: B127A-002-BH, B127A-002-BHPH2, B127A-004-BH, B127A-004-BHPH3, B127A-008-BH |
| General | |
| Device Type | Video/audio extender (receiver) |
| Form Factor | External |
| Color | Gray, black |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI (output) - Type A male ¦ 1 x network (input) - RJ-45 female |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | Plug and Play, FCC, RoHS, REACH, EDID compatible |
| TAA Compliant | Yes |
| Networking | |
| Connectivity Technology | Wired |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Max Transfer Distance | 230 ft |
| Status Indicators | Status |
| Features | 3D support, video mirror mode, 7.1 channel audio support, integrated equalizer, LPCM 7.1 support, 36-bit Deep Color support, LPCM 5.1 support, HDR support, 4:4:4 chroma subsampling support, LPCM 2.0 support |
| Compliant Standards | HDCP 1.4, HDCP 2.2 |
| Power | |
| Power Over Ethernet (PoE) | PoC |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 85% (non-condensing) |
| Dimensions & Weight | |
| Width | 1.9 in |
| Depth | 2.9 in |
| Height | 0.7 in |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 7.9 in |
| Shipping Depth | 5.6 in |
| Shipping Height | 1.7 in |
| Shipping Weight | 5.61 oz |
| Compatibility Information | |
| Designed For | P/N: B127A-002-BH, B127A-002-BHPH2, B127A-004-BH, B127A-004-BHPH3, B127A-008-BH |
