KVM / audio / USB switch - 8 x KVM / audio / USB - 1 local user - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite series DisplayPort/USB KVM Switch 8-Port with Audio/Video and USB Peripheral Sharing, 4K 60 Hz, 1U Rack-Mount - KVM / audio / USB switch - 8 ports - rack-mountable |
| Device Type | KVM / audio / USB switch - 8 ports - cascadable |
| Enclosure Type | Rack-mountable 1U |
| Subtype | KVM |
| Ports | 8 x KVM / audio / USB |
| KVM Users Qty | 1 local user |
| Features | 2.1 channel audio support |
| Power | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) | 17 in x 8.4 in x 1.7 in |
| Weight | 6.86 lbs |
| Color | Black |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | KVM / audio / USB switch - 8 ports - cascadable |
| Enclosure Type | Rack-mountable 1U |
| Subtype | KVM |
| Ports | 8 x KVM / audio / USB |
| KVM Local Users Qty | 1 local user |
| Keyboard / Mouse Interface | USB |
| Max Resolution | 4096 x 2160 @ 60 Hz |
| Features | 2.1 channel audio support |
| Expansion / Connectivity | |
| Interfaces | 8 x DisplayPort input ¦ 8 x keyboard (USB) / mouse (USB) Type B ¦ 8 x audio mini-jack ¦ 1 x DisplayPort output ¦ 1 x console (audio) mini-jack ¦ 1 x mouse (USB) Type A ¦ 1 x keyboard (USB) Type A ¦ 2 x console (USB) Type A ¦ 2 x USB 3.0 Type A ¦ 1 x audio mini-jack |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Color | Black |
| Included Accessories | 4 rubber feet, 19" rack mounting kit |
| Cables Included | 1 x power cable (C13-C14) - 4 ft ¦ 2 x DisplayPort 1.4 cable - 5 ft ¦ 2 x USB-B to USB-A cable - 6 ft ¦ 2 x audio cable - 6 ft ¦ 1 x firmware upgrade cable - 6 ft |
| Rack Mounting Kit | Included |
| Compliant Standards | CCC, China RoHS, GS, LPS, PSE Mark, RoHS, TUV, UL, WEEE, cUL, NOM, REACH, DisplayPort 1.2, HDCP 2.2 |
| Power | |
| Power Device | External power adapter |
| Power Provided | 12 V - 3.33 A |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 18.44 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 80% (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 140 °F |
| Dimensions & Weight | |
| Width | 17 in |
| Depth | 8.4 in |
| Height | 1.7 in |
| Weight | 6.86 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 19.6 in |
| Shipping Depth | 12.8 in |
| Shipping Height | 5.2 in |
| Shipping Weight | 10.56 lbs |
