360° VR camera - mountable - 3D - APS-C - 12K / 60 fps - 24.0 MP - SSD 4 TB - solid state drive - Bluetooth, Wi-Fi 6
| Main Specifications | |
|---|---|
| Product Description | Kandao Obsidian Pro - VR camera - solid state drive |
| Product Type | VR camera - 3D - 12K |
| Action Camera Type | Mountable |
| Synchronized Camera Array | Spherical panorama |
| Media Type | Solid state drive |
| Memory Card Slot | microSD card |
| Sensors | 9-axis gyro sensor |
| Internal Storage | 4 TB SSD |
| Wireless Interface | Bluetooth, Wi-Fi 6 |
| Sensor Resolution | 8 x 24.0 MP |
| Max Video Resolution | 11520 x 11520 |
| Lens System | 8 x fisheye lens 6.6 mm f/2.8 |
| Focus Adjustment | Motorized |
| Interface | HDMI, USB-C |
| Dimensions (WxDxH) | 9.3 in x 9.3 in x 14.5 in |
| Weight | 24.6 lbs |
| General | |
| Product Type | VR camera - 12K |
| Sensor Resolution | 8 x |
| Camcorder Sensor Resolution | 24.0 MP |
| Sensor Qty | 1 CMOS |
| 3D Technology | Yes |
| 360° Camera | Yes |
| Camcorder Media Type | Solid state drive |
| Optical Sensor Type | CMOS |
| Optical Sensor Size | APS-C (23.4 x 15.7 mm) |
| Frame Rate (Max Resolution) | 60 fps |
| ISO (Max) | 12800 |
| Navigation | GPS receiver |
| Sensors | 9-axis gyro sensor |
| Features | Proxy recording |
| Digital Video Format | H.265, KDRAW, ProRes 422 HQ |
| Image Recording Format | JPEG, DNG (RAW), DNG (RAW) + JPEG |
| Max Video Resolution | 11520 x 11520 |
| Interface | HDMI, USB-C, Bluetooth 5.0, IEEE 802.11ax |
| Miscellaneous | |
| Included Accessories | AC power adapter |
| Lens System | |
| Type | 8 x fisheye lens 6.6 f/2.8 - fisheye |
| Focus Adjustment | Motorized |
| Max View Angle | 195 degrees |
| Lens Construction | 10 groups / 14 elements |
| Memory / Storage | |
| Memory Card Slot | microSD card |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Internal Storage | 4 TB SSD |
| Additional Features | |
| Additional Features | Audio recording, built-in sapphire IR sensor |
| Connections | |
| Connector Type | Network (RJ-45) ¦ Audio line-in / microphone (mini-phone stereo 3.5 mm) ¦ USB (USB Type-C) ¦ HDMI (19 pin HDMI Type A) ¦ DC power input (4 pin Lemo) |
| Microphone | |
| Microphone Operation Mode | Omni-directional x 8 |
| Dimensions & Weight | |
| Width | 9.3 in |
| Depth | 9.3 in |
| Height | 14.5 in |
| Weight | 24.6 lbs |
| Exposure & White Balance | |
| Light Sensitivity | ISO 100-12800 |
| Exposure Modes | Automatic |
| White Balance | Automatic |
| Action Camera Features | |
| Camera Type | Mountable |
| Features | Time-Lapse recording |
| Tripod Mount | |
| Connection Point | 1/4" & 3/8" socket |
| 360° Camera | |
| Panorama Type | Spherical |
| Optical Sensor Qty | 8 |
