Barcode scanner - integrated - decoded - USB
| Main Specifications | |
|---|---|
| Product Description | HP - barcode scanner |
| Type | Barcode scanner - integrated - stationary - USB - decoded |
| Color | Black |
| Localization | English / United States |
| Scan Element Type | CMOS - white LED / red LED |
| Sensor Resolution | 1200 x 800 |
| System Requirements | Windows 10 IoT Enterprise 2016 LTSB 64-bit Edition (RS1), Windows 10 IoT Enterprise 2019 LTSC 64-bit Edition (RS5), Windows 10 Pro 64-bit Edition, CentOS 5.6.8 (64-bit) or later, Red Hat Linux, SUSE Linux Enterprise Desktop 11 64-bit, SuSE Linux Enterprise Server 12 SP3 (64-bit) or later, Ubuntu 12.04, Ubuntu 14.04 LTS (64-bit) or later, Android 8.0 (Oreo) or later |
| Dimensions (WxDxH) | 1.2 in x 1.8 in x 0.4 in |
| Weight | 0.53 oz |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Type | Barcode scanner - integrated - stationary |
| Color | Black |
| Localization | English / United States |
| Expansion / Connectivity | |
| Interfaces | 1 x USB |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance hardware replacement - 3 years |
| Miscellaneous | |
| Compliant Standards | IP54, FCC Part 15 Class B, EMC Class B, IEC 62471, RoHS, IEC 62368-1 |
| Power | |
| Power Consumption Operational | 3 watt |
| Electric Current Required | 500-700 mA (operating), 800 mA (maximum), 1 mA (sleep), 70 mA (idle) |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| System Requirements | |
| OS Required | Windows 10 IoT Enterprise 2016 LTSB 64-bit Edition (RS1), Windows 10 IoT Enterprise 2019 LTSC 64-bit Edition (RS5), Windows 10 Pro 64-bit Edition, CentOS 5.6.8 (64-bit) or later, Red Hat Linux, SUSE Linux Enterprise Desktop 11 64-bit, SuSE Linux Enterprise Server 12 SP3 (64-bit) or later, Ubuntu 12.04, Ubuntu 14.04 LTS (64-bit) or later, Android 8.0 (Oreo) or later |
| Dimensions & Weight | |
| Width | 1.2 in |
| Depth | 1.8 in |
| Height | 0.4 in |
| Weight | 0.53 oz |
| Barcode | |
| Interface Type | USB |
| Scan Element Type | CMOS - white LED / red LED |
| Sensor Resolution | 1200 x 800 |
| Light Source Wave Length | 625 nm |
| Scan Mode | Fixed projection |
| Max Working Distance | 9.6 in |
| Skew (Degrees) | 60 |
| Pitch (Degrees) | 60 |
| Decode Capability | Aztec code, Chinese Sensible Code, Code One, Data Matrix, China GM Code, MaxiCode, MicroPDF417, Micro QR code, PDF417, QR code, Australian Post, Kix (Netherlands) Post, Royal Mail, US Planet, US Postnet, GS1 DataBar |
| TTL Decoding | Decoded |
| Features | Passport reader |
