Device server - 2 ports - 100Mb LAN, RS-232 - desktop / wall / DIN rail mountable
| Main Specifications | |
|---|---|
| Product Description | ATEN Altusen SN3002P - device server |
| Device Type | Device server |
| Form Factor | Desktop / wall / DIN rail mountable |
| Ports Qty | 2 |
| Data Link Protocol | Ethernet, Fast Ethernet, RS-232 |
| Included Accessories | Terminal block connector, feet set, DIN-rail mounting kit |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 4.6 in x 3.9 in x 1 in |
| Weight | 7.76 oz |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Device server |
| Width | 4.6 in |
| Depth | 3.9 in |
| Height | 1 in |
| Weight | 7.76 oz |
| Expansion / Connectivity | |
| Interfaces | 2 x RS-232 - DB-9 ¦ 1 x 100Base-TX - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Terminal block connector, feet set, DIN-rail mounting kit |
| Compliant Standards | EN 55032, EN 55035, CISPR 32, FCC Part 15 B Class A, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, RoHS, UL 60950-1, UL 62368-1 |
| Networking | |
| Form Factor | Desktop / wall / DIN rail mountable |
| Ports Qty | 2 |
| Connectivity Technology | Wired |
| Data Transfer Rate | 921.6 Kbps |
| Data Link Protocol | Ethernet, Fast Ethernet, RS-232 |
| Network / Transport Protocol | TCP/IP, UDP/IP |
| Remote Management Protocol | Telnet, SSH, SNMP 1, SNMP 2c |
| Status Indicators | Power, status, port status, port transmission speed |
| Features | Reset button, flow control, 1.5 KV Magnetic Isolation, 4KV ESD Protector (contact discharge), 8KV ESD Protector (air-gap discharge), metal housing, RADIUS support, IP address filtering, event notification, SNMP trap, NTP server |
| Compliant Standards | IEEE 802.3af |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
