Expansion module - HDMI x 2 + RS-232 x 2
| Main Specifications | |
|---|---|
| Product Description | Kramer F676-OUT2-F16 - expansion module - HDMI x 2 + RS-232 x 2 |
| Device Type | Expansion module |
| Form Factor | Plug-in module |
| Ports | HDMI x 2 + RS-232 x 2 |
| Dimensions (WxDxH) | 7.5 in x 5.1 in x 0.8 in |
| Weight | 7.05 oz |
| Data Link Protocol | HDMI, RS-232 |
| Data Transfer Rate | 10.2 Gbps |
| Compliant Standards | HDCP 2.2, IEEE 802.3ae |
| General | |
| Device Type | Expansion module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 2 x HDMI output - LC multi-mode - female - x 2 ¦ 2 x RS-232 - 3 pin terminal block |
| Miscellaneous | |
| Included Accessories | 2 x SFP+ multimode transceivers |
| Compliant Standards | OM3, UL, RoHS, WEEE |
| Networking | |
| Ports | HDMI x 2 + RS-232 x 2 |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI, RS-232 |
| Data Transfer Rate | 10.2 Gbps |
| Status Indicators | Receive, transmit |
| Features | 4K resolution support, LPCM 7.1 support, Dolby TrueHD support, DTS-HD support, I-EDIDPro Kramer Intelligent EDID Processing |
| Compliant Standards | HDCP 2.2, IEEE 802.3ae |
| Power | |
| Power Consumption Operational | 9 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 7.5 in |
| Depth | 5.1 in |
| Height | 0.8 in |
| Weight | 7.05 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 9.4 in |
| Shipping Depth | 6.6 in |
| Shipping Height | 2.3 in |
| Shipping Weight | 10.58 oz |
