Wireless router - WWAN 1GbE - WAN ports: 3 - Wi-Fi 5
| Main Specifications | |
|---|---|
| Product Description | Pepwave MAX HD4 MBX 5G - wireless router - WWAN - Wi-Fi 5 - desktop |
| Device Type | Wireless router - wireless cellular modem |
| Enclosure Type | Desktop |
| Cellular Band | LTE B13, LTE B17, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B25, LTE B26, LTE B5, LTE B39, LTE B28, LTE B29, LTE B8, LTE B66, LTE B30, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19, LTE B46, LTE B14, LTE B32, LTE B42, LTE B48, LTE B71, LTE B34 |
| WAN Ports Qty | 3 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Performance | Routing throughput: 2.5 Gbps ¦ PepVPN/SpeedFusion throughput: 600 Mbps ¦ PepVPN/SpeedFusion throughput (256-bit AES): 500 Mbps |
| Capacity | Recommended users: 50 - 500 |
| Features | PoE, fanless |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac |
| Dimensions (WxDxH) | 11.5 in x 7 in x 1.7 in |
| Weight | 7.28 lbs |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Performance | Routing throughput: 2.5 Gbps ¦ PepVPN/SpeedFusion throughput: 600 Mbps ¦ PepVPN/SpeedFusion throughput (256-bit AES): 500 Mbps |
| Capacity | Recommended users: 50 - 500 |
| Features | PoE, fanless |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, FCC, RoHS, E Mark, PTCRB, EN 61000, IEC 61373, EN 61373, EN 50155 |
| Status Indicators | Power, status, cellular mode |
| Expansion / Connectivity | |
| Interfaces | WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 8 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 ¦ USB: 2 x 4 pin USB Type A ¦ Antenna: 8 x SMA ¦ Antenna: 4 x RP-SMA - Wi-Fi ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Antenna: 1 x SMA - GPS |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Included Accessories | GPS antenna, mounting brackets, 4 x Wi-Fi antennas, 8 x 2 dBi LTE antennas |
| Power | |
| Power Device | External power adapter |
| Power Consumption Operational | 55 watt |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 149 °F |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Communications | |
| Type | 2 x wireless cellular modem |
| Cellular Band | LTE B13, LTE B17, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B25, LTE B26, LTE B5, LTE B39, LTE B28, LTE B29, LTE B8, LTE B66, LTE B30, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19, LTE B46, LTE B14, LTE B32, LTE B42, LTE B48, LTE B71, LTE B34 |
| Max Transfer Rate | 4 Gbps |
| Dimensions & Weight | |
| Width | 11.5 in |
| Depth | 7 in |
| Height | 1.7 in |
| Weight | 7.28 lbs |
