Media converter - 1GbE - 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X - RJ-45 / SFP (mini-GBIC)
| Main Specifications | |
|---|---|
| Product Description | Black Box - media converter - 10Mb LAN, 100Mb LAN, 1GbE |
| Device Type | Media converter - RJ-45 / SFP (mini-GBIC) |
| Form Factor | External |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Power Over Ethernet (PoE) | PoE++ |
| Power | AC 120/230 V |
| Dimensions (WxDxH) | 4.5 in x 6 in x 1 in |
| Weight | 17.64 oz |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Media converter |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female ¦ 1 x network - SFP |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Compliant Standards | UL, FCC, RoHS, REACH |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Features | Wall mountable, DIN rail mountable |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Power | |
| Power Over Ethernet (PoE) | PoE++ |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 4.5 in |
| Depth | 6 in |
| Height | 1 in |
| Weight | 17.64 oz |
