Motherboard - mini ITX - Socket AM4 - AMD X570 Chipset - USB 3.2 Gen 1, USB 3.2 Gen 2 - 2 x 10 Gigabit LAN - onboard graphics
| Main Specifications | |
|---|---|
| Product Description | ASRock Rack X570D4I-2T - motherboard - mini ITX - Socket AM4 - AMD X570 |
| Product Type | Motherboard - mini ITX |
| Chipset Type | AMD X570 |
| Processor Socket | 1 x Socket AM4 |
| Compatible Processors | Ryzen (supports 3rd Generation Ryzen, Maximum TDP 105 Watt) |
| RAM Supported | 4 SO-DIMM slots - DDR4, non-ECC, ECC, unbuffered |
| Storage Ports | 2 x OCuLink port, 1 x M.2 |
| USB / FireWire Ports | 2 x USB 3.2 Gen 2 + (2 x USB 3.2 Gen 1 via headers) |
| Graphics | ASPEED AST2500 |
| Dedicated Video Memory | 16 MB |
| LAN | 2 x 10 Gigabit Ethernet |
| General | |
| Product Type | Motherboard - mini ITX |
| Chipset Type | AMD X570 |
| Processor Socket | Socket AM4 |
| Max Processors Qty | 1 |
| Compatible Processors | Ryzen (supports 3rd Generation Ryzen, Maximum TDP 105 Watt) |
| Expansion / Connectivity | |
| Expansion Slots | 1 x CPU ¦ 4 x SO-DIMM 260-pin ¦ 1 x PCIe 4.0 x16 |
| Storage Interfaces | SATA-600 / PCIe 4.0 -connectors: 2 x OCuLink - 8 devices ¦ SATA-600 / PCIe 4.0 -connectors: 1 x M.2 |
| Interfaces | 2 x USB 3.2 Gen 2 ¦ 1 x VGA ¦ 2 x LAN (10Gigabit Ethernet) ¦ 1 x management |
| Internal Interfaces | 1 x serial - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x speaker - header |
| Power Connectors | DC-in power connector, 4-pin ATX12V connector |
| Miscellaneous | |
| Width | 6.7 in |
| Depth | 6.7 in |
| Features | |
| BIOS Type | AMI |
| BIOS Features | ACPI 2.0 support, SMBIOS 2.8 support |
| Hardware Monitoring | CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage |
| Sleep / Wake Up | Wake on LAN (WOL) |
| Hardware Features | Energy Efficient Ethernet 802.3az, Dual LAN Teaming, Preboot eXecution Environment (PXE), ASRock Rack Instant Flash |
| LAN | |
| Network Controller | Intel X550-AT2 |
| Network Interfaces | 2 x 10 Gigabit Ethernet |
| Graphics | |
| Graphics Controller | ASPEED AST2500 |
| Dedicated Video Memory | 16 MB |
| Supported RAM | |
| Technology | DDR4 |
| Bus Clock | 2933 MHz |
| Supported RAM Integrity Check | Non-ECC, ECC |
| Registered or Buffered | Unbuffered |
