Switch - 28 x 10 Gigabit SFP+ + 4 x 25 Gigabit SFP28 - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Ubiquiti UniFi Switch Pro Aggregation - switch - rack-mountable |
| Device Type | Switch |
| Enclosure Type | Rack-mountable |
| Subtype | 10 Gigabit Ethernet |
| Ports | 28 x 10 Gigabit SFP+ + 4 x 25 Gigabit SFP28 |
| Performance | Non-blocking switching throughput: 380 Gbps ¦ Switching capacity: 760 Gbps ¦ Forwarding rate: 565.44 Mpps |
| Features | 16KV ESD Protector (air-gap discharge), 12KV ESD Protector (contact discharge), DHCP server, Inter-VLAN Routing, static routing |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 17.4 in x 12.8 in x 1.7 in |
| Weight | 10.14 lbs |
| General | |
| Device Type | Switch |
| Enclosure Type | Rack-mountable |
| Subtype | 10 Gigabit Ethernet |
| Ports | 28 x 10 Gigabit SFP+ + 4 x 25 Gigabit SFP28 |
| Performance | Non-blocking switching throughput: 380 Gbps ¦ Switching capacity: 760 Gbps ¦ Forwarding rate: 565.44 Mpps |
| Features | 16KV ESD Protector (air-gap discharge), 12KV ESD Protector (contact discharge), DHCP server, Inter-VLAN Routing, static routing |
| Built-in Devices | 1.3" touch screen display |
| Status Indicators | Link/activity |
| Expansion / Connectivity | |
| Interfaces | 28 x 10Gbit LAN SFP+ ¦ 4 x 25Gbit LAN SFP28 |
| Miscellaneous | |
| Compliant Standards | FCC, IC |
| Power | |
| Power Device | Internal power supply |
| Power Provided | 100 watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 100 watt |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 17.4 in |
| Depth | 12.8 in |
| Height | 1.7 in |
| Weight | 10.14 lbs |
