Wireless access point - Wi-Fi 6 - 2.4 GHz, 5 GHz - wall / ceiling mountable
| Main Specifications | |
|---|---|
| Product Description | NETGEAR Insight Managed WiFi 6 AX3600 Dual Band Multi-Gig Access Point with Power Adapter - wireless access point - Wi-Fi 6 |
| Device Type | Wireless access point |
| Form Factor | Wall / ceiling mountable - indoor |
| Localization | United States |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum throughput (5 GHz): 2400 Mbps ¦ Maximum throughput (2.4 GHz): 1200 Mbps |
| Capacity | Streams: 8 ¦ SSIDs total: 8 |
| Included Accessories | Wall/ceiling mounting kit |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Dimensions (WxDxH) | 8.1 in x 8.1 in x 1.4 in |
| Weight | 27.62 oz |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Indoor |
| Width | 8.1 in |
| Depth | 8.1 in |
| Height | 1.4 in |
| Weight | 27.62 oz |
| Localization | United States |
| Expansion / Connectivity | |
| Interfaces | 1 x 1/2.5GBase-T (PoE+) - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - 5 years - response time: next business day ¦ Technical support - 90 days |
| Miscellaneous | |
| Included Accessories | Wall/ceiling mounting kit |
| Networking | |
| Form Factor | Wall / ceiling mountable |
| Connectivity Technology | Wireless |
| Line Coding Format | OFDMA, OFDM |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Spread Spectrum Method | OFDMA, OFDM |
| Remote Management Protocol | WAP, RADIUS |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum throughput (5 GHz): 2400 Mbps ¦ Maximum throughput (2.4 GHz): 1200 Mbps |
| Capacity | Streams: 8 ¦ SSIDs total: 8 |
| Wi-Fi Rating | AX3600 |
| Status Indicators | Power, LAN, 2.4/5 GHz |
| Features | 4x4 MU-MIMO technology, VLAN support, BSS Coloring, Target Wait Time (TWT), Beamforming+, WDS bridge, WDS PTMP (Point to Multipoint), WDS PTP (Point to Point), WDS repeater mode, MAC address filtering, 802.1x authentication, Neighbor AP detection, Block SSID Broadcast, Guest Network, Captive Portal, bandwidth control, LLDP support, band steering, Backhaul Technology, Wi-Fi Multimedia (WMM) support, Wireless Distribution System (WDS) support, auto-uplink (auto MDI/MDI-X), Transmit Power Control (TPC) |
| Encryption Algorithm | WPA-Enterprise, SSL, WPA, WPA2, WPA3, TLS, TTLS, PEAP, WPA2-Enterprise |
| Authentication Method | RADIUS, Extensible Authentication Protocol (EAP) |
| Compliant Standards | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6, IEEE 802.3at, IEEE 802.3af, IEEE 802.11i, IEEE 802.1x, IEEE 802.1ab (LLDP) |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Power Device | External power adapter |
| Installed Qty | 1 |
| Software / System Requirements | |
| Software Included | NETGEAR Insight (1 year subscription) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Antenna | |
| Antenna | Internal |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
