Wireless router - WWAN 1GbE - WAN ports: 2 - Wi-Fi 5
| Main Specifications | |
|---|---|
| Product Description | Pepwave PDX - wireless router - WWAN - Wi-Fi 5 - desktop |
| Device Type | Wireless router - wireless cellular modem |
| Enclosure Type | Desktop |
| Cellular Band | LTE B13, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B26, LTE B5, LTE B29, LTE B8, LTE B66, LTE B30, LTE B41, LTE B18, LTE B19, LTE B46, LTE B9, LTE B14, LTE B32, LTE B42, LTE B43, LTE B48 |
| WAN Ports Qty | 2 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Performance | Routing throughput: 2.5 Gbps ¦ PepVPN/SpeedFusion throughput: 600 Mbps ¦ PepVPN/SpeedFusion throughput (256-bit AES): 500 Mbps |
| Capacity | Recommended users: 50 - 500 |
| Features | PoE, battery powered, 2x2 MIMO technology |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Power | AC 120/230 V / DC 12 - 56 V |
| Dimensions (WxDxH) | 19.7 in x 14.8 in x 7.7 in |
| Weight | 28.66 lbs |
| Localization | Americas |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Performance | Routing throughput: 2.5 Gbps ¦ PepVPN/SpeedFusion throughput: 600 Mbps ¦ PepVPN/SpeedFusion throughput (256-bit AES): 500 Mbps |
| Capacity | Recommended users: 50 - 500 |
| Features | PoE, battery powered, 2x2 MIMO technology |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IC, FCC, IP65, IP55, MIL-STD-810H |
| Expansion / Connectivity | |
| Interfaces | WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 7 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Localization | Americas |
| Power | |
| Voltage Required | AC 120/230 V / DC 12 - 56 V |
| Power Consumption Operational | 38 Watt |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Communications | |
| Type | 4 x wireless cellular modem |
| Cellular Band | LTE B13, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B26, LTE B5, LTE B29, LTE B8, LTE B66, LTE B30, LTE B41, LTE B18, LTE B19, LTE B46, LTE B9, LTE B14, LTE B32, LTE B42, LTE B43, LTE B48 |
| Max Transfer Rate | 600 Mbps |
| Dimensions & Weight | |
| Width | 19.7 in |
| Depth | 14.8 in |
| Height | 7.7 in |
| Weight | 28.66 lbs |
| Antenna | |
| Antenna | Internal |
