Security appliance - 8 ports - 1GbE, RS-232 - LTE
| Main Specifications | |
|---|---|
| Product Description | Lantronix Edge Management Gateway 7500 - security appliance - LTE |
| Device Type | Security appliance |
| Form Factor | External |
| RAM | 1 GB |
| Flash Memory | 1 GB |
| Ports Qty | 8 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232, LTE |
| Cellular Protocol | LTE |
| Dimensions (WxDxH) | 5.7 in x 6.4 in x 1.7 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Security appliance |
| Width | 5.7 in |
| Depth | 6.4 in |
| Height | 1.7 in |
| Expansion / Connectivity | |
| Interfaces | 8 x RS-232 - RJ-45 ¦ 2 x Ethernet 1000 - RJ-45 ¦ 1 x management (USB) - Type A ¦ 1 x console - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | UL, CB, IC, FCC, FIPS 140-2, FIPS 197 |
| Networking | |
| Form Factor | External |
| Ports Qty | 8 |
| Connectivity Technology | Wired, wireless |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232, LTE |
| Network / Transport Protocol | TCP/IP, UDP/IP |
| Routing Protocol | RIP, RIP-2 |
| Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, SSH, CLI, SFTP, DHCP |
| Features | Firewall protection, Syslog support, packet filtering, IPv6 support, e-mail notification, Management Information Base (MIB), VPN client, Network Timing Protocol (NTP), Lights Out Management (LOM), BOOTP support |
| Encryption Algorithm | TLS 1.0, TLS 1.1, TLS 1.2, TLS 1.3 |
| Authentication Method | RADIUS, TACACS+, Kerberos |
| Power | |
| Power Consumption Operational | 20 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 30 - 90% (non-condensing) |
| Communications | |
| Cellular Protocol | LTE |
| Supported Flash Memory Cards | microSD |
| Processor / Memory / Storage | |
| RAM | 1 GB |
| Flash Memory | 1 GB |
