Wireless router 1GbE - Wi-Fi 5 - Dual Band
| Main Specifications | |
|---|---|
| Product Description | Tenda 4G09 - wireless router - Wi-Fi 5 - desktop |
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| Cellular Protocol | WCDMA |
| Cellular Band | LTE B2, LTE B4, LTE B3, LTE B7, LTE B20, LTE B1, LTE B5, LTE B28, LTE B8, LTE B40, LTE B38 |
| WAN Ports Qty | 1 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 1200 Mbps |
| Network / Transport Protocol | PPTP, L2TP, DDNS |
| Remote Management Protocol | TR-069 |
| Features | Firewall protection, VPN support, IPv6 support, parental control, firmware upgradable, QoS, virtual server support, roaming function, WPS, DHCP server, port forwarding, reset button, IPv4 support, DHCP client, Beamforming+, scheduler, failover protection, guest access, DMZ support, DynDNS, L2TP client, PPTP client, PPTP server, WPS button |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 5 in x 7.3 in x 2.4 in |
| Weight | 12.34 oz |
| General | |
| Device Type | Wireless router |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 1200 Mbps |
| Network / Transport Protocol | PPTP, L2TP, DDNS |
| Remote Management Protocol | TR-069 |
| Encryption Algorithm | WPA, WPA2, WPA-PSK, WPA2-PSK, WEP |
| Wi-Fi Rating | AC1200 |
| Features | Firewall protection, VPN support, IPv6 support, parental control, firmware upgradable, QoS, virtual server support, roaming function, WPS, DHCP server, port forwarding, reset button, IPv4 support, DHCP client, Beamforming+, scheduler, failover protection, guest access, DMZ support, DynDNS, L2TP client, PPTP client, PPTP server, WPS button |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, UPnP, IEEE 802.11ac, FCC, RoHS |
| Status Indicators | Power, LAN, Internet, Wi-Fi, 3G/4G |
| Expansion / Connectivity | |
| Interfaces | WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Expansion Slots | 2 SIM |
| Miscellaneous | |
| Cables Included | 1 x network cable |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Communications | |
| Cellular Protocol | WCDMA |
| Cellular Band | LTE B2, LTE B4, LTE B3, LTE B7, LTE B20, LTE B1, LTE B5, LTE B28, LTE B8, LTE B40, LTE B38 |
| Dimensions & Weight | |
| Width | 5 in |
| Depth | 7.3 in |
| Height | 2.4 in |
| Weight | 12.34 oz |
| Antenna | |
| Antenna | External detachable and internal |
| Antenna Qty | 4 |
