System bus extender - 400 Watt
| Main Specifications | |
|---|---|
| Product Description | Sonnet Echo III Rackmount - system bus extender |
| Product Type | System bus extender |
| Dimensions (WxDxH) | 19 in x 16.5 in x 3.6 in |
| Weight | 23.15 lbs |
| Power | Power adapter AC 115 - 230 V (50 - 60 Hz) 400 Watt Power Provided |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | System bus extender |
| Width | 19 in |
| Depth | 16.5 in |
| Height | 3.6 in |
| Weight | 23.15 lbs |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x PCI Express 3.0 x16 - full-length, full-height ¦ 2 (total) / 2 (free) x PCI Express 3.0 x8 - full-length, full-height |
| Interfaces | 2 x Thunderbolt 3 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x Thunderbolt 3 cable - external - 2.3 ft |
| Included Accessories | Thunderbolt 3 cable lock |
| Features | Built-in 2 cooling fans, rack-mountable, 2U height |
| Compliant Standards | IEC 62368-1, Directive 2015/863, RoHS3, IEC 62368-2 |
| Power | |
| Power Device | Power adapter |
| Voltage Required | AC 115 - 230 V (50 - 60 Hz) |
| Power Provided | 400 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| System Requirements | |
| OS Required | Windows 10 64-bit Edition, Apple macOS Sierra 10.12.6 or later, Linux Kernel 5.0 or later |
