SSD - 1 TB - internal - M.2 2280 - PCIe 4.0 x4 (NVMe)
| Main Specifications | |
|---|---|
| Product Description | Sabrent Rocket 4 PLUS - SSD - 1 TB - PCIe 4.0 x4 (NVMe) |
| Type | Solid state drive - internal |
| Capacity | 1 TB |
| NAND Flash Memory Type | 3D triple-level cell (TLC) |
| Form Factor | M.2 2280 |
| Interface | PCIe 4.0 x4 (NVMe) |
| Features | NVM Express (NVMe) 1.3, Active State Power Management (ASPM), Autonomous Power State Transition (APST), L1.2 low-power mode, TRIM support, ONFi 2.3 flash, ONFi 3.0 flash, ONFi 3.2 flash, ONFi 4.0 flash, Advanced Wear Leveling, Bad Block Management, Error Correction Code (ECC), Over Provision, upgradable firmware, Phison PS5018-E18 controller, DDR4 DRAM Cache, S.M.A.R.T. |
| Dimensions (WxDxH) | 0.9 in x 3.1 in x 0.1 in |
| Manufacturer Warranty | 5-year warranty with product registration |
| General | |
| Device Type | Solid state drive - internal |
| Capacity | 1 TB |
| NAND Flash Memory Type | 3D triple-level cell (TLC) |
| Form Factor | M.2 2280 |
| Interface | PCIe 4.0 x4 (NVMe) |
| Features | NVM Express (NVMe) 1.3, Active State Power Management (ASPM), Autonomous Power State Transition (APST), L1.2 low-power mode, TRIM support, ONFi 2.3 flash, ONFi 3.0 flash, ONFi 3.2 flash, ONFi 4.0 flash, Advanced Wear Leveling, Bad Block Management, Error Correction Code (ECC), Over Provision, upgradable firmware, Phison PS5018-E18 controller, DDR4 DRAM Cache, S.M.A.R.T. |
| Width | 0.9 in |
| Depth | 3.1 in |
| Height | 0.1 in |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years with product registration |
| Miscellaneous | |
| Compliant Standards | FCC, VCCI, BSMI, RoHS |
| Power | |
| Power Consumption | 6.3 Watt (read) ¦ 6.6 Watt (write) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 185 °F |
| Shock Tolerance (operating) | 1500 g |
| Performance | |
| SSD Endurance | 700 TB |
| Internal Data Rate | 7000 MBps (read) / 5300 MBps (write) |
| 4KB Random Read | 350000 IOPS |
| 4KB Random Write | 700000 IOPS |
| Reliability | |
| MTBF | 1,600,000 hours |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 4 in |
| Shipping Depth | 2.8 in |
| Shipping Height | 0.5 in |
| Shipping Weight | 2.4 oz |
| Software & System Requirements | |
| Software Included | Acronis True Image |
| Expansion & Connectivity | |
| Interfaces | 1 x PCI Express 4.0 x4 (NVMe) - M.2 Card |
| Compatible Bay | M.2 2280 |
