Switch - managed - 8 x 10 Gigabit SFP+ - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Ubiquiti UniFi Switch USW-Aggregation - switch - 8 ports - managed - rack-mountable |
| Device Type | Switch - 8 ports - managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 8 x 10 Gigabit SFP+ |
| Performance | Non-blocking switching throughput: 80 Gbps ¦ Switching capacity: 160 Gbps ¦ Forwarding rate: 119.04 Mbps |
| Features | 16KV ESD Protector (air-gap discharge), 12KV ESD Protector (contact discharge), fanless, layer 2 switching |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 17.4 in x 4.7 in x 1.7 in |
| Weight | 5.84 lbs |
| General | |
| Device Type | Switch - 8 ports - managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 8 x 10 Gigabit SFP+ |
| Performance | Non-blocking switching throughput: 80 Gbps ¦ Switching capacity: 160 Gbps ¦ Forwarding rate: 119.04 Mbps |
| Features | 16KV ESD Protector (air-gap discharge), 12KV ESD Protector (contact discharge), fanless, layer 2 switching |
| Built-in Devices | 1.3" touch screen display |
| Status Indicators | System, SFP+, firmware, steady |
| Expansion / Connectivity | |
| Interfaces | 8 x 10Gbit LAN SFP+ |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC, IC |
| Power | |
| Power Device | Internal power supply |
| Power Provided | 36 watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 30 watt |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 17.4 in |
| Depth | 4.7 in |
| Height | 1.7 in |
| Weight | 5.84 lbs |
