Switch - managed - front to back airflow - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Extreme Networks Extreme 9920-NPB-8 - switch - managed - rack-mountable |
| Device Type | Switch - managed |
| Enclosure Type | Front to back airflow rack-mountable |
| Performance | Switching capacity: 25.6 Tbps |
| Capacity | Packet buffer size: 22 MB |
| Dimensions (WxDxH) | 17.2 in x 22 in x 6.8 in |
| Weight | 72.75 lbs |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Switch - managed |
| Enclosure Type | Front to back airflow rack-mountable |
| Performance | Switching capacity: 25.6 Tbps |
| Capacity | Packet buffer size: 22 MB |
| RAM | 128 GB |
| Built-in Devices | 2 x 120 GB SSD |
| Expansion / Connectivity | |
| Interfaces | 1 x console RJ-45 ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x Type A ¦ 1 x console (USB) mini-USB |
| Expansion Slots | 8 (total) / 8 (free) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Compliant Standards | RoHS 2011/65/EU, WEEE 2012/19/EU, ASTM D3580, SJ/T 11364-2014, EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2, EN/ETSI 300 019-2-2 v2.1.2 - Class 2.3, EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e, CNS 15663, EN/ETSI 300 753 (1997-10) |
| Power | |
| Power Device | Internal power supply (not installed) |
| Max Supported Qty | 4 |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 5 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 22 in |
| Height | 6.8 in |
| Weight | 72.75 lbs |
