KVM console - USB - US - English (QWERTY) - 17.3" - rack-mountable - 3840 x 2160 4K @ 60 Hz - 400 cd/m² - 1000:1 - HDMI, DisplayPort, USB - black - 1U - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | NTI RACKMUX 4K17-N - KVM console - 4K - 17.3" - TAA Compliant |
| Device Type | KVM console - 17.3" |
| KVM Switch | USB |
| Keyboard Layout | US - English (QWERTY) |
| Features | Touchpad, 100 keys keyboard |
| Native Resolution | 4K 3840 x 2160 (DisplayPort: 60 Hz, HDMI: 30 Hz) |
| Pixel Pitch | 0.0997 mm |
| Brightness | 400 cd/m² |
| Contrast Ratio | 1000:1 |
| Color Support | 16.7 million colors |
| Input Connectors | HDMI, DisplayPort, USB |
| Display Position Adjustments | Tilt |
| Voltage | AC 120/230 V (50/60 Hz) |
| Color | Black |
| Dimensions (WxDxH) | 19 in x 23.9 in x 1.7 in |
| Height (Rack Units) | 1U |
| Weight | 26.01 lbs |
| TAA Compliant | Yes |
| Compliant Standards | RoHS, DisplayPort 1.2a, HDCP 2.2, HDCP 1.4, VESA DDC 2 B |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Display Type | KVM console / TFT active matrix |
| Diagonal Size | 17.3" |
| Native Resolution | 4K 3840 x 2160 (DisplayPort: 60 Hz, HDMI: 30 Hz) |
| Pixel Pitch | 0.0997 mm |
| Brightness | 400 cd/m² |
| Contrast Ratio | 1000:1 |
| Color Support | 16.7 million colors |
| Backlight Technology | LED backlight |
| Features | Auto Power Off, 8-bit Color Depth |
| Color | Black |
| Dimensions (WxDxH) | 19 in x 23.9 in x 1.7 in |
| Height (Rack Units) | 1U |
| Weight | 26.01 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 2 years |
| Miscellaneous | |
| Features | LCD display, powder coated, rugged, lockable, integrated cable management, numeric pad |
| Included Accessories | 2 keys |
| Cables Included | 1 x HDMI cable - 6 ft ¦ 1 x DisplayPort cable - 6 ft ¦ 1 x USB type A to USB type B cable - 6 ft |
| Rack Mounting Kit | Included |
| Compliant Standards | RoHS, DisplayPort 1.2a, HDCP 2.2, HDCP 1.4, VESA DDC 2 B |
| TAA Compliant | Yes |
| Power | |
| Input Voltage | AC 120/230 V (50/60 Hz) |
| Power Consumption (Typical) | 30 Watt |
| Software / System Requirements | |
| OS Required | Apple MacOS, Linux, Microsoft Windows 2000 Server, FreeBSD, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Oracle Solaris, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/10, Microsoft Windows Server 2019 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 90% (non-condensing) |
| Connectivity | |
| Interfaces | HDMI ¦ DisplayPort ¦ USB (Type B) ¦ USB 2.0 (Type A) |
| KVM | |
| Keyboard / Mouse Interface | USB |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Input | |
| Type | Touchpad, 100 keys keyboard |
| Mechanical | |
| Display Position Adjustments | Tilt |
| Tilt Angle | 120 |
