Network adapter - USB-C 3.1 Gen 1 - Gigabit Ethernet x 1
| Main Specifications | |
|---|---|
| Product Description | j5create JCE133G - network adapter - USB-C 3.1 Gen 1 - Gigabit Ethernet x 1 |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C 3.1 Gen 1 |
| Ports | Gigabit Ethernet x 1 |
| Dimensions (WxDxH) | 2.7 in x 0.6 in x 0.9 in |
| Weight | 1.16 oz |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Data Transfer Rate | 1 Gbps |
| Network / Transport Protocol | TCP/IP, UDP/IP |
| Compliant Standards | IEEE 802.3az-2010, USB 3.1 Gen 1, USB 1.1, USB 2.0, USB 3.0 |
| System Requirements | Apple MacOS, Microsoft Windows, Microsoft Windows XP / Vista / 7 / 8.1 / 10, Apple MacOS X 10.6 or later, Linux Kernel 4.15, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Google Chrome OS |
| General | |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C 3.1 Gen 1 |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000 - RJ-45 - female |
| Miscellaneous | |
| Cables Included | 1 x USB-C cable (integrated) - 3.9 in |
| Compliant Standards | Plug and Play |
| Networking | |
| Ports | Gigabit Ethernet x 1 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Network / Transport Protocol | TCP/IP, UDP/IP |
| Status Indicators | Link/activity |
| Features | WOL, EEE, IPv6 support, IPv4 support, USB powered, aluminum housing |
| Compliant Standards | IEEE 802.3az-2010, USB 3.1 Gen 1, USB 1.1, USB 2.0, USB 3.0 |
| Software / System Requirements | |
| OS Required | Apple MacOS, Microsoft Windows, Microsoft Windows XP / Vista / 7 / 8.1 / 10, Apple MacOS X 10.6 or later, Linux Kernel 4.15, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2016, Google Chrome OS |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 149 °F |
| Humidity Range Operating | 0 - 85% (non-condensing) |
| Dimensions & Weight | |
| Width | 2.7 in |
| Depth | 0.6 in |
| Height | 0.9 in |
| Weight | 1.16 oz |
