Video/audio/infrared/serial extender - HDBaseT - up to 230 ft
| Main Specifications | |
|---|---|
| Product Description | WyreStorm 18Gbps 4K HDR HDBaseT Extender with True ARC and Audio Breakout - video/audio/infrared/serial extender - HDBaseT |
| Device Type | Video/audio/infrared/serial extender |
| Form Factor | External |
| Data Link Protocol | HDBaseT |
| Max Transfer Distance | 230 ft |
| Dimensions (WxDxH) | 7.7 in x 3.7 in x 0.8 in |
| Weight | 12.7 oz |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Video/audio/infrared/serial extender |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI (input) - 19 pin HDMI Type A ¦ 1 x SPDIF (output) - TOSLINK ¦ 1 x audio (output) - 3 pin Phoenix ¦ 1 x HDMI (output) - 19 pin HDMI Type A ¦ 1 x IrDA (input) - mini jack ¦ 1 x IrDA (output) - mini jack ¦ 1 x RS-232 (input) - 3 pin Phoenix ¦ 1 x RS-232 (output) - 3 pin Phoenix |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS, EDID compatible |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDBaseT |
| Max Resolution | 4096 x 2160 @ 60 Hz |
| Max Video Bandwidth | 600 MHz |
| Max Transfer Distance | 230 ft |
| Features | Audio Return Channel (ARC), 4K resolution support, 7.1 channel audio support, power over HDBaseT (PoH), Dolby Atmos support, DTS:X support, HDR 4K60 4:4:4 compatible, HDR10 support, Dolby Vision HDR support, Hybrid Log-Gamma (HLG) support, Visually Lossless Compression |
| Compliant Standards | HDCP 2.2 |
| Power | |
| Power Device | External power adapter |
| Power Consumption Operational | 8.88 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 7.7 in |
| Depth | 3.7 in |
| Height | 0.8 in |
| Weight | 12.7 oz |
