Video/audio/infrared/serial extender - HDBaseT - up to 230 ft
| Main Specifications | |
|---|---|
| Product Description | WyreStorm 4K UHD HDBaseT Extender Set with 2-way PoH and Bidirectional IR & RS-232 - video/audio/infrared/serial extender - HDBaseT |
| Device Type | Video/audio/infrared/serial extender |
| Form Factor | External |
| Localization | United Kingdom, United States, Europe |
| Data Link Protocol | HDBaseT |
| Max Transfer Distance | 230 ft |
| Power | AC 120/230 V |
| Dimensions (WxDxH) | 4.3 in x 2.5 in x 0.6 in |
| Weight | 6 oz |
| General | |
| Device Type | Video/audio/infrared/serial extender |
| Form Factor | External |
| Localization | United Kingdom, United States, Europe |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI - 19 pin HDMI Type A ¦ 1 x RS-232 - terminal block ¦ 1 x IrDA (output) - mini jack ¦ 1 x IrDA (input) - mini jack |
| Miscellaneous | |
| Included Accessories | 2 x IR receivers, 2 x IR transmitters |
| Mounting Kit | Included |
| Compliant Standards | RoHS, FCC, EDID compatible |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDBaseT |
| Max Resolution | 4096 x 2160 @ 60 Hz |
| Max Transfer Distance | 230 ft |
| Features | HDCP compliant, 4K resolution support, HDBaseT technology, DTS:X support, Dolby Atmos support, 7.1 channel audio support, power over HDBaseT (PoH), 3D support, EDID Management |
| Compliant Standards | HDCP 2.2 |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 8.88 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 4.3 in |
| Depth | 2.5 in |
| Height | 0.6 in |
| Weight | 6 oz |
