Docking station - USB-C / Thunderbolt 3 - HDMI
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series USB C Docking Station HDMI USB-A SD/Micro SD PD Charging Gray - docking station - USB-C / Thunderbolt 3 - HDMI |
| Product Type | Docking station |
| Docking Interface | USB-C / Thunderbolt 3 |
| Video Interfaces | HDMI |
| Dimensions (WxDxH) | 3.9 in x 0.4 in x 1.3 in |
| Weight | 2.47 oz |
| Color | Gray |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | Docking station |
| Width | 3.9 in |
| Depth | 0.4 in |
| Height | 1.3 in |
| Weight | 2.47 oz |
| Enclosure Color | Gray |
| Expansion / Connectivity | |
| Expansion Slots | 1 SD Memory Card ¦ 1 microSD |
| Interfaces | 1 x USB-C with Power Delivery (60 W) - 24 pin USB-C ¦ 1 x USB-C / Thunderbolt 3 - 24 pin USB-C ¦ 1 x USB 2.0 - 9 pin USB Type A ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x headset - input / output - mini-phone stereo 3.5 mm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Input Device | SD card reader, microSD card reader |
| Features | LED indicator, bus powered, box package, quick mount clip |
| Compliant Standards | Plug and Play, FCC, RoHS, REACH, HDCP 1.4 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Video | |
| Max Resolution Details | 3840 x 2160 - 30 Hz (HDMI only) |
