Switch - managed - 10 x 10/100/1000 + 2 x 10GBase-SR SFP+
| Main Specifications | |
|---|---|
| Product Description | Yamaha SWP2 Series SWP2-10MMF - switch - 10 ports - managed |
| Device Type | Switch - 10 ports - managed |
| Ports | 10 x 10/100/1000 + 2 x 10GBase-SR SFP+ |
| Routing Protocol | MSTP |
| Features | Layer 2 switching, Dante audio network, QoS, IGMP snooping, built-in DIP switch, auto-negotiation, auto-uplink (auto MDI/MDI-X), metal housing |
| Compliant Standards | IEEE 802.3, IEEE 802.3ae |
| Power | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) | 18.9 in x 14.3 in x 1.7 in |
| Weight | 10.14 lbs |
| General | |
| Device Type | Switch - 10 ports - managed |
| Ports | 10 x 10/100/1000 + 2 x 10GBase-SR SFP+ |
| Routing Protocol | MSTP |
| Authentication Method | RADIUS |
| Features | Layer 2 switching, Dante audio network, QoS, IGMP snooping, built-in DIP switch, auto-negotiation, auto-uplink (auto MDI/MDI-X), metal housing |
| Compliant Standards | IEEE 802.3, IEEE 802.3ae |
| Status Indicators | Link/activity, status, VLAN, power |
| Expansion / Connectivity | |
| Interfaces | 10 x 10/100/1000 Base-T EtherCON ¦ 2 x 10GBase-SR SFP+ ¦ 1 x console RJ-45 |
| Miscellaneous | |
| Included Accessories | Power cable |
| Compliant Standards | RoHS |
| Power | |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 21 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 140 °F |
| Dimensions & Weight | |
| Width | 18.9 in |
| Depth | 14.3 in |
| Height | 1.7 in |
| Weight | 10.14 lbs |
