Network adapter - USB-C 3.2 Gen 1 / Thunderbolt 3 - 10M/100M/1G/2.5 Gigabit Ethernet x 1 - black
| Main Specifications | |
|---|---|
| Product Description | Manhattan USB-C to 2.5GBASE-T Gigabit (10/100/1000 Mbps & 2.5 Gbps) RJ45 Network Adapter, Multi-Gigabit Ethernet, Black, Three Year Warranty, Box - network adapter - USB-C 3.2 Gen 1 / Thunderbolt 3 - 10M/100M/1G/2.5 Gigabit Ethernet x 1 |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C 3.2 Gen 1 / Thunderbolt 3 |
| Ports | 10M/100M/1G/2.5 Gigabit Ethernet x 1 |
| Dimensions (WxDxH) | 1 in x 3 in x 0.6 in |
| Weight | 1.2 oz |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 2.5GBase-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE |
| Capacity | Jumbo frame size: up to 9 KB |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3x, IEEE 802.3az, IEEE 802.3bz, USB 3.2 Gen 1 |
| Color | Black |
| System Requirements | Microsoft Windows 7 / 8 / 8.1 / 10, Apple macOS 10.14.x, Linux 3.2, Linux 3.10, Linux 3.12, Linux 4.2, Linux 4.4 |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB-C 3.2 Gen 1 / Thunderbolt 3 |
| Expansion / Connectivity | |
| Interfaces | 1 x 2.5Gb Ethernet - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | 1 x USB 3.2 Gen 1 cable (integrated) - 7.7 in |
| Compliant Standards | FCC, RoHS, EMI, WEEE 2012/19/EU |
| Color | Black |
| Networking | |
| Ports | 10M/100M/1G/2.5 Gigabit Ethernet x 1 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 2.5GBase-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Capacity | Jumbo frame size: up to 9 KB |
| Status Indicators | Link/activity |
| Features | Flow control, auto-sensing per device, full duplex mode, USB powered, plastic housing, Energy Efficient Ethernet, Back Pressure Support, Thunderbolt 3 compatible, VLAN Tagging |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3x, IEEE 802.3az, IEEE 802.3bz, USB 3.2 Gen 1 |
| Software / System Requirements | |
| OS Required | Microsoft Windows 7 / 8 / 8.1 / 10, Apple macOS 10.14.x, Linux 3.2, Linux 3.10, Linux 3.12, Linux 4.2, Linux 4.4 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 1 in |
| Depth | 3 in |
| Height | 0.6 in |
| Weight | 1.2 oz |
