Wireless access point - Wi-Fi 5 - 2.4 GHz, 5 GHz - cloud-managed - wall / ceiling mountable
| Main Specifications | |
|---|---|
| Product Description | Grandstream GWN7605 - wireless access point - Wi-Fi 5 - cloud-managed |
| Device Type | Wireless access point |
| Form Factor | Wall / ceiling mountable - indoor |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum data rate (2.4 GHz): 300 Mbps ¦ Maximum data rate (5 GHz): 867 Mbps ¦ Channel bandwidth (5 GHz): 20 / 40 / 80 MHz ¦ Channel bandwidth (2.4 GHz): 20 / 40 MHz |
| Capacity | Maximum number of configured SSIDs: 8 ¦ Number of concurrent clients: 100+ ¦ Manageable access points: up to 50 |
| Included Accessories | Wall mounting kit, ceiling mounting kit |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Dimensions (WxDxH) | 7.1 in x 1.6 in x 7.1 in |
| Weight | 13.69 oz |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Indoor |
| Width | 7.1 in |
| Depth | 1.6 in |
| Height | 7.1 in |
| Weight | 13.69 oz |
| Expansion / Connectivity | |
| Interfaces | 2 x 1000Base-T (PoE+) - RJ-45 |
| Miscellaneous | |
| Included Accessories | Wall mounting kit, ceiling mounting kit |
| Compliant Standards | IC, FCC, RCM, IEEE 802.3af, IEEE 802.3at |
| Networking | |
| Form Factor | Wall / ceiling mountable |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1.27 Gbps |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Cloud-Managed | Yes |
| Frequency Band | 2.4 GHz, 5 GHz |
| Max Range Open Space | 541 ft |
| Performance | Maximum data rate (2.4 GHz): 300 Mbps ¦ Maximum data rate (5 GHz): 867 Mbps ¦ Channel bandwidth (5 GHz): 20 / 40 / 80 MHz ¦ Channel bandwidth (2.4 GHz): 20 / 40 MHz |
| Capacity | Maximum number of configured SSIDs: 8 ¦ Number of concurrent clients: 100+ ¦ Manageable access points: up to 50 |
| Status Indicators | Status, device tracking |
| Features | Auto-sensing per device, VLAN support, IPv6 support, wall mountable, Wi-Fi Multimedia (WMM) support, Multiple SSID support, reset button, IPv4 support, ceiling mountable, security lock slot (cable lock sold separately), Type of Service (ToS), beamforming technology, secure boot, Advanced QoS, 2x2:2 MU-MIMO technology, data/control lockdown, 2x3:2 MIMO technology |
| Encryption Algorithm | AES, TKIP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WEP |
| Authentication Method | Radio Service Set ID (SSID) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11e, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac Wave 2 |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Power Consumption Operational | 10.16 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 9 in |
| Shipping Depth | 3.1 in |
| Shipping Height | 8.7 in |
| Shipping Weight | 25.37 oz |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 2 |
| Gain Level | 3 dBi |
