80" Diagonal Class 4T-B Series LED-backlit LCD display - with TV tuner - digital signage - 4K UHD (2160p) 3840 x 2160 - direct-lit LED
| Main Specifications | |
|---|---|
| Product Description | Sharp 4T-B80CJ1U 4T-B Series - 80" LED-backlit LCD display - 4K - for digital signage |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 80" |
| Commercial Use | Yes - digital signage |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Video Interface | Composite, HDMI |
| HDMI Ports Qty | 2 ports |
| Connectivity | LAN |
| LCD Backlight Technology | Direct-lit LED |
| Image Aspect Ratio | 16:9 |
| Digital TV Tuner | ATSC |
| Analog TV Tuner | NTSC |
| Speaker System | 2 speakers |
| USB | Yes |
| Voltage | AC 120/230 V (60 Hz) |
| Power Consumption Operational | 138 watt |
| Dimensions (WxDxH) - without stand | 71.9 in x 3.2 in x 41.4 in |
| Weight | 77.82 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption Operational | 138 watt |
| Diagonal Class | 80" |
| Commercial Use | Yes - digital signage |
| Series | 4T-B Series |
| TV Tuner Presence | Yes |
| Video Interface | Composite, HDMI |
| HDMI Ports Qty | 2 ports |
| Modes | Public Mode |
| Dimensions | Without stand |
| Width | 71.9 in |
| Depth | 3.2 in |
| Height | 41.4 in |
| Weight | 77.82 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | Plug and Play, VESA DDC 2 B |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 120/230 V (60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Display | |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| LCD Backlight Technology | Direct-lit LED |
| Image Contrast Ratio | 4000:1 |
| Brightness | 300 cd/m² |
| Viewing Angle | 176° |
| Viewing Angle (Vertical) | 176° |
| Response Time | 8.5 ms |
| Operation Hours / Days | 16 / 7 |
| Connections | |
| Connector Type | 2 x HDMI ¦ Composite video input ¦ RS-232C ¦ USB ¦ Audio line-out ¦ LAN |
| Video Features | |
| Analog Video Input Signals | NTSC, PAL-M, PAL-N |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 watt |
| Additional Features | Built-in Dolby MS11 Multistream decoder |
| Speakers | 2 x speaker - 10 watt |
| TV Tuner | |
| Analog TV Tuner | NTSC |
| Reception System | PAL-M, NTSC-M, PAL-N |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 76.8 in |
| Depth (Shipping) | 8.5 in |
| Height (Shipping) | 46.5 in |
| Weight (Shipping) | 104.5 lbs |
| Network & Internet Multimedia | |
| Connectivity | LAN |
| LAN Protocol | Ethernet |
| Digital TV Tuner | |
| Digital TV Tuner | ATSC |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 1 |
