Control processor - 2 ports - 1GbE - 1U - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Atlona Velocity System AT-VGW-HW-3 - control processor |
| Device Type | Control processor |
| Form Factor | Rack-mountable - 1U |
| Ports Qty | 2 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Capacity | Rooms of AV control: 3 ¦ Simultaneous connections: 250 |
| Dimensions (WxDxH) | 8.6 in x 4.5 in x 1.7 in |
| Manufacturer Warranty | 10-year warranty |
| General | |
| Device Type | Control processor |
| Height (Rack Units) | 1U |
| Width | 8.6 in |
| Depth | 4.5 in |
| Height | 1.7 in |
| Expansion / Connectivity | |
| Interfaces | 2 x 1000Base-T - RJ-45 ¦ 1 x USB-C ¦ 3 x USB 3.0 ¦ 1 x HDMI ¦ 1 x mini DisplayPort output |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 10 years |
| Miscellaneous | |
| Compliant Standards | TUV, BSMI, CCC, FCC, ETL, PSE Mark, KC, EAC, RCM |
| Networking | |
| Form Factor | Rack-mountable |
| Ports Qty | 2 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | TCP/IP, UDP/IP, DHCP |
| Remote Management Protocol | SNMP, HTTP, HTTPS, SSH, SFTP, SMTP |
| Capacity | Rooms of AV control: 3 ¦ Simultaneous connections: 250 |
| Encryption Algorithm | TLS, 128-bit AES |
| Power | |
| Power Consumption Operational | 55 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 20 - 90% (non-condensing) |
