Power amplifier - 2 x 100 Watt
| Main Specifications | |
|---|---|
| Product Description | Extron XPA U 1002-70V - power amplifier |
| Product Type | Power amplifier |
| Audio Specifications | Amplifier - 20 - 20000 Hz - 100 dB 0.1% |
| Power | AC 100/230 V (50 - 60 Hz) |
| Dimensions (WxDxH) | 8.7 in x 10.5 in x 1.7 in |
| Weight | 3.31 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | Power amplifier |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Power | |
| Voltage Required | AC 100/230 V (50 - 60 Hz) |
| Connections | |
| Connectors | 2 x balanced audio input (terminal block) - rear ¦ 2 x speakers output (terminal block) - rear |
| Dimensions & Weight | |
| Width | 8.7 in |
| Depth | 10.5 in |
| Height | 1.7 in |
| Weight | 3.31 lbs |
| Audio System | |
| Functions | Amplifier |
| Amplifier Class | D |
| Audio Specifications | Amplifier - Response Bandwidth - 20 - 20000 Hz - SNR - 100 dB - THD - 0.1% |
| Output Channel Qty | 2 channels |
| Output Power (per channel) | 100 Watt |
| Amplifier Output Details | 100 Watt - at 1 kHz - THD 0.1% - 2 channels (70V) |
| Features | 70V operation |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 14 in |
| Depth (Shipping) | 15 in |
| Height (Shipping) | 5 in |
| Weight (Shipping) | 5 lbs |
