USB peripheral sharing switch - 3 x USB 3.2 Gen 2 + 1 x USB-C (power delivery) - desktop
| Main Specifications | |
|---|---|
| Product Description | ATEN US3342 - USB peripheral sharing switch |
| Device Type | USB peripheral sharing switch |
| Subtype | USB |
| Ports | 3 x USB 3.2 Gen 2 + 1 x USB-C (power delivery) |
| Performance | Data transfer rate: 10 Gbps |
| Features | USB powered, USB Power Delivery (up to 85 watt), BEZEL X |
| Compliant Standards | Power Delivery 3.0, USB 3.2 Gen 2 |
| Dimensions (WxDxH) | 3.5 in x 5.6 in x 0.9 in |
| Weight | 9.17 oz |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | USB peripheral sharing switch |
| Enclosure Type | Desktop |
| Subtype | USB |
| Ports | 3 x USB 3.2 Gen 2 + 1 x USB-C (power delivery) |
| Performance | Data transfer rate: 10 Gbps |
| Features | USB powered, USB Power Delivery (up to 85 watt), BEZEL X |
| Compliant Standards | Power Delivery 3.0, USB 3.2 Gen 2 |
| Status Indicators | Select |
| Expansion / Connectivity | |
| Interfaces | 3 x USB 3.2 Gen 2 Type A ¦ 2 x USB-C input ¦ 1 x USB-C (power delivery) ¦ 1 x remote control mini-jack ¦ 1 x USB 3.2 Gen 2 Type C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Remote port selector switch |
| Cables Included | 2 x USB 3.1 Gen 2 cable |
| Power | |
| Power Consumption Operational | 0.43 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 80% (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 140 °F |
| Dimensions & Weight | |
| Width | 3.5 in |
| Depth | 5.6 in |
| Height | 0.9 in |
| Weight | 9.17 oz |
