PoE injector - AC 100/240 V - 33 Watt - output connectors: 1
| Main Specifications | |
|---|---|
| Product Description | Black Box - PoE injector - 33 Watt |
| Device Type | PoE injector - external |
| Power Over Ethernet (PoE) | PoE+ |
| Weight | 7.05 oz |
| Input Voltage | AC 100/240 V |
| Output Voltage | 54 - 57 V |
| Power Capacity | 33 Watt |
| Input Connectors | 1 x RJ-45, power IEC 60320 |
| Output connectors | 1 x RJ-45 |
| Dimensions (WxDxH) | 1.8 in x 5.5 in x 1.1 in |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | PoE injector - external |
| Power Over Ethernet (PoE) | PoE+ (IEEE 802.3at) |
| Expansion / Connectivity | |
| Interfaces | 1 x Gigabit LAN - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Features | PoE injector function, overcurrent protection, overvoltage protection, overload protection |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at, Plug and Play, UL, cUL, RoHS |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
| Power Device | |
| Input Voltage | AC 100/240 V |
| Input Voltage Range | AC 90 - 264 V |
| Frequency Required | 47 - 63 Hz |
| Input Connectors | 1 x RJ-45, power IEC 60320 |
| Power Output Connectors Details | 1 x RJ-45 |
| Output Voltage | 54 - 57 V |
| Power Capacity | 33 Watt |
| Circuit Protection | Circuit breaker |
| Dimensions & Weight | |
| Width | 1.8 in |
| Depth | 5.5 in |
| Height | 1.1 in |
| Weight | 7.05 oz |
