55" Diagonal Class LED-backlit LCD display - interactive digital signage - 1080p 1920 x 1080 - direct-lit LED
| Main Specifications | |
|---|---|
| Product Description | NEC MultiSync UN552VS 55" LED-backlit LCD display - Full HD - for digital signage / interactive communication |
| Product Type | LED-backlit LCD flat panel display |
| Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/424892 |
| Diagonal Class | 55" |
| Commercial Use | Yes - interactive digital signage |
| Resolution | 1920 x 1080 |
| Display Format | 1080p |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | Composite, HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | DVI, VGA (HD-15), DisplayPort |
| Technology | S-IPS |
| LCD Backlight Technology | Direct-lit LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Picture Enhancements | Noise Reduction, Adaptive Contrast, 6 color adjustment |
| Supported Memory Cards | microSDHC |
| USB | Yes |
| Included Accessories | Clamp, SD card cover slot |
| Voltage | AC 120/230 V (50/60 Hz) |
| Energy Class | Class G |
| Power Consumption Operational | 165 Watt |
| Power Consumption (On mode) | 201 W |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) - without stand | 47.7 in x 3.9 in x 26.8 in |
| Weight | 56.88 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Energy Label QR Code URL | Https://eprel.ec.europa.eu/qr/424892 |
| Energy Class | Class G |
| Power Consumption Operational | 165 Watt |
| Power Consumption (On mode) | 201 W |
| Power Consumption SDR (On mode) | 201 kWh/1000h |
| Diagonal Class | 55" |
| Commercial Use | Yes - interactive digital signage |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | NFC sensor |
| Video Interface | Composite, HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | DVI, VGA (HD-15), DisplayPort |
| Modes | Portrait mode, landscape mode, picture modes |
| Picture Enhancements | Noise Reduction, Adaptive Contrast, 6 color adjustment |
| Cooling System | Advanced cooling system |
| Dimensions | Without stand |
| Width | 47.7 in |
| Depth | 3.9 in |
| Height | 26.8 in |
| Weight | 56.88 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Miscellaneous | |
| Included Accessories | Clamp, SD card cover slot |
| Cables Included | DisplayPort cable - 6.6 ft ¦ HDMI cable - 6.6 ft ¦ Network cable |
| Compliant Standards | VESA DPMS, DisplayPort 1.2, VESA TMDS, HDCP 2.2, HDCP 1.3, HDCP 1.4, DisplayPort 1.1 |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 120/230 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| On / Off Switch | Yes |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Display | |
| LCD Display Technology | S-IPS |
| Resolution | 1920 x 1080 |
| Display Format | 1080p |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct-lit LED |
| Image Contrast Ratio | 1100:1 |
| Brightness | 500 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Response Time | 8 ms |
| Additional Features | Scheduler Function (with RTC), TileComp, TileMatrix, Carbon Footprint Meter, Frame Comp, Input Labeling, Expansion Slot, screen saver, SpectraView Engine support, Auto Tile Matrix, 3D LUT Setting, UHD Daisychaining, OPS Slot, HDR emulation, white copy function |
| Connections | |
| Connector Type | VGA / component video input ¦ 2 x DisplayPort input ¦ 2 x HDMI input ¦ DisplayPort output ¦ HDMI output ¦ 2 x audio input ¦ DVI-D input ¦ RS-232C input ¦ Remote control ¦ USB ¦ Composite video input ¦ 2 x LAN ¦ USB 2.0 downstream ¦ USB ¦ 2 x speakers output ¦ USB 2.0 upstream ¦ USB (power only) ¦ Service |
| Audio System | |
| External Speakers Amplifier Power (Total) | 30 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 56.5 in |
| Depth (Shipping) | 12.5 in |
| Height (Shipping) | 34.4 in |
| Weight (Shipping) | 81.57 lbs |
| Stands & Mounts | |
| Stand | Optional |
| Flat Panel Mount Interface | 400 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| Supported Memory Cards | microSDHC |
| USB Port | Yes |
| USB Ports Qty | 1 |
