110" Diagonal Class FA Series LED video wall - digital signage 1920 x 1080 110" - SMD
| Main Specifications | |
|---|---|
| Product Description | NEC LED-FA012I2-110 FA Series - 110" LED video wall - for digital signage |
| Product Type | LED video wall |
| Diagonal Class | 110" |
| Commercial Use | Yes - digital signage |
| Resolution | 1920 x 1080 |
| Frame Rate & Enhancement Technology | 2880 Hz Refresh Rate |
| Max Number of Screens | 16 |
| Video Interface | HDMI |
| PC Interface | DVI |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Video Wall Display Unit | 110" - SMD - 480 x 270 |
| USB | Yes |
| Included Accessories | Removal tool, pixel card service tool, 2 x LED controllers, overframe kit (4x4), LED modules (16 cabinets, 128 pixel cards), wall mount (4x4) |
| Dimensions (WxDxH) | 97.3 in x 3.2 in x 58.6 in |
| Weight | 401.24 lbs |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | LED video wall |
| Diagonal Class | 110" |
| Commercial Use | Yes - digital signage |
| Series | FA Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| PC Interface | DVI |
| Modes | Landscape mode |
| Width | 97.3 in |
| Depth | 3.2 in |
| Height | 58.6 in |
| Weight | 401.24 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Removal tool, pixel card service tool, 2 x LED controllers, overframe kit (4x4), LED modules (16 cabinets, 128 pixel cards), wall mount (4x4) |
| Compliant Standards | FCC Class A certified, CCC, RoHS, ETL, IP20 |
| Power | |
| Video Wall Display Unit Power Consumption (Max) | 200 W |
| Video Wall Display Unit Power Consumption (Typical) | 912 W |
| Video Wall Power Consumption (Max) | 800 W/m² |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% |
| Display | |
| Resolution | 1920 x 1080 |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 2880 Hz Refresh Rate |
| Color Temperature | 3000 - 9500K |
| Image Contrast Ratio | 5000:1 |
| Brightness | 800 cd/m² |
| Viewing Angle | 170° |
| Viewing Angle (Vertical) | 170° |
| Additional Features | Direct-View LED Technology |
| Connections | |
| Connector Type | USB ¦ DVI-D input ¦ HDMI input ¦ RS-232 ¦ LAN ¦ Genlock |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 1 |
| Video Wall Display Unit | |
| Pixel Pitch | 1.2 mm |
| Pixel Density | 623269 pixels/m² |
| LED Type | SMD |
| Resolution | 480 x 270 |
| LED Lifetime | 100000 hours |
| Maintenance | Front |
| Cabinet Diagonal Size | 110" |
| Video Wall | |
| Max Number of Screens | 16 |
