Power control unit (plug-in module) - 30A, controlled, iso ground, hardwired - output connectors: 1 - black powder coat
| Main Specifications | |
|---|---|
| Product Description | Middle Atlantic MPR Series - power control unit - 30A, controlled, iso ground, hardwired |
| Device Type | Power control unit - plug-in module |
| Output Voltage | AC 120 V |
| Output connectors | 1 x power NEMA L5-30R - 120 V 30 A |
| Color | Black powder coat |
| Dimensions (WxDxH) | 8 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Power control unit - plug-in module |
| Color | Black powder coat |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Features | Isolated, hardwired |
| Compliant Standards | ETL, UL 5A, UL 5, CSA C22.2 No. 62 |
| Power Device | |
| Frequency Provided | 60 Hz |
| Power Output Connectors Details | 1 x power NEMA L5-30R - 120 V 30 A |
| Output Voltage | AC 120 V 60 Hz |
| Dimensions & Weight | |
| Height | 8 in |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 17.64 oz |
