Wireless network extender 1GbE - WAN ports: 2 - Wi-Fi 5 - Dual Band
| Main Specifications | |
|---|---|
| Product Description | Zyxel Multy Pro WAP6804 - wireless network extender - Wi-Fi 5 - desktop |
| Device Type | Wireless network extender |
| Enclosure Type | Desktop |
| WAN Ports Qty | 2 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 2.1 Gbps |
| Remote Management Protocol | Telnet, HTTP, CLI, TR-069, TR-098, TR-181 |
| Features | IGMP snooping, MAC address filtering, Access Point operational mode, firmware upgradable, WMM support, ACS, QoS, WPS, reset button, DHCP client, dual firmware images, beamforming technology, 4x4 MU-MIMO technology, MDI, MDI-X |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Power | DC 12 V |
| Dimensions (WxDxH) | 5.4 in x 1.1 in x 7.6 in |
| Weight | 10.25 oz |
| General | |
| Device Type | Wireless network extender |
| Enclosure Type | Desktop |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Frequency Band | 2.4 GHz / 5 GHz |
| Data Transfer Rate | 2.1 Gbps |
| Remote Management Protocol | Telnet, HTTP, CLI, TR-069, TR-098, TR-181 |
| Encryption Algorithm | WPA-PSK, WPA2-PSK |
| Authentication Method | Radio Service Set ID (SSID) |
| Wi-Fi Rating | AC2100 |
| Features | IGMP snooping, MAC address filtering, Access Point operational mode, firmware upgradable, WMM support, ACS, QoS, WPS, reset button, DHCP client, dual firmware images, beamforming technology, 4x4 MU-MIMO technology, MDI, MDI-X |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Status Indicators | Power, LAN, operation mode, WPS, 2.4 GHz, link, 5G |
| Expansion / Connectivity | |
| Interfaces | LAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Miscellaneous | |
| Cables Included | 1 x network cable |
| Power | |
| Power Device | External power adapter |
| Voltage Required | DC 12 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 5.4 in |
| Depth | 1.1 in |
| Height | 7.6 in |
| Weight | 10.25 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 12.6 in |
| Shipping Depth | 2.8 in |
| Shipping Height | 6.8 in |
| Shipping Weight | 12.56 oz |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 6 |
