Docking station - USB-C - VGA, HDMI, DP - 1GbE
| Main Specifications | |
|---|---|
| Product Description | SIIG USB-C MST Video Docking Station with PD - docking station - USB-C - VGA, HDMI, DP - 1GbE |
| Product Type | Docking station |
| Docking Interface | USB-C |
| Video Interfaces | VGA, HDMI, DP |
| Dimensions (WxDxH) | 10.2 in x 3.5 in x 0.9 in |
| Weight | 12.31 oz |
| Color | Black, iron gray |
| Networking | Gigabit Ethernet |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Docking station |
| Width | 10.2 in |
| Depth | 3.5 in |
| Height | 0.9 in |
| Weight | 12.31 oz |
| Enclosure Color | Black, iron gray |
| Expansion / Connectivity | |
| Interfaces | 1 x USB 2.0 - 4 pin USB Type A ¦ 1 x USB-C with Power Delivery (100 W) - 24 pin USB-C (power only) ¦ 1 x video - VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 1 x audio / video - HDMI output - 19 pin HDMI Type A ¦ 2 x SuperSpeed USB 3.0 with Battery Charging 1.2 - 9 pin USB Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x audio - input / output - mini-phone stereo 3.5 mm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Input Device | SD card reader, microSD card reader |
| Features | 4K Ultra HD, MST (multi-stream transport), 100W power delivery |
| Compliant Standards | FCC, RoHS |
| Networking | |
| Data Link Protocol | Gigabit Ethernet |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| System Requirements | |
| OS Required | Microsoft Windows 7 / 8 / 10, Apple macOS 10.13 or later |
