Network / USB adapter - PCIe 2.0 - Gigabit Ethernet + USB 3.0 x 3 - black
| Main Specifications | |
|---|---|
| Product Description | SIIG USB 3.0 3-Port Hub with LAN PCIe Host Card - network / USB adapter - PCIe 2.0 - Gigabit Ethernet + USB 3.0 x 3 |
| Device Type | Network / USB adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 2.0 x1 |
| PCI Specification Revision | PCIe 2.0 |
| Ports | Gigabit Ethernet + USB 3.0 x 3 |
| Dimensions (WxDxH) | 0.8 in x 4.7 in x 2.6 in |
| Weight | 1.76 oz |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, USB 3.0 |
| Compliant Standards | USB 1.1, USB 2.0, USB 3.0 |
| Color | Black |
| System Requirements | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows Server 2003, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows 7 (32/64 bits), Windows 8 (32/64 bits), Windows 8.1 (32/64 bits), Windows 10 (32/64 bits) |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Device Type | Network / USB adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 2.0 x1 |
| PCI Specification Revision | PCIe 2.0 |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T - RJ-45 ¦ 3 x USB 3.0 - 9 pin USB Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS |
| Color | Black |
| Networking | |
| Ports | Gigabit Ethernet + USB 3.0 x 3 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, SuperSpeed USB 3.0 |
| Features | UASP |
| Compliant Standards | USB 1.1, USB 2.0, USB 3.0 |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows Server 2003, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows 7 (32/64 bits), Windows 8 (32/64 bits), Windows 8.1 (32/64 bits), Windows 10 (32/64 bits) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 0.8 in |
| Depth | 4.7 in |
| Height | 2.6 in |
| Weight | 1.76 oz |
